Specifications
application :
Automotive Industry
pressure :
Other
warranty :
1 year
Brand Name :
RV
Place of Origin :
Shanghai, China
customized support :
OEM, ODM
power source :
Pneumatic
structure :
Diaphragm Pump
voltage :
Penumatic
Material :
Aluminum
Name :
Diaphragm Pump
Color :
black
Weight :
4.5kgs
Diaphragm :
Hytrel
Brand :
RV
Packing :
carton
Max pressure :
100psi(0.7Mpa,7bar)
Pump body :
Aluminum
Max Flow :
15gpm(57lpm)
MOQ :
2 sets
Price :
$196 / set
Description
AODD Paint Pumps
Professional manufacturer specializing in air-operated double diaphragm pumps for paint and coating applications.
Product Specifications
Plastic Diaphragm Pump with 15gpm Max Flow 100psi Max Pressure and Hytrel Diaphragm for Automotive Industry
Max Working Pressure 100 psi (0.7Mpa, 7bar)
Max Flow Rate 15gpm (57L/M)
Max Reciprocating Speed 400cpm
Max Suction Height (Dry Sucking) 4.5m
Max Permitted Grain 3/32in. (2.5mm)
Max Air Consumption 20scfm (10L/S)
Air Inlet Size 1/4 in
Air Outlet Size 3/8 in
Fluid Inlet Size 1/2 3/4 in
Fluid Outlet Size 1/2 3/4 in
Weight Aluminum pump: 4.5KGS, Stainless steel pump: 6.8KGS
Plastic Diaphragm Pump with 15gpm Max Flow 100psi Max Pressure and Hytrel Diaphragm for Automotive Industry Plastic Diaphragm Pump with 15gpm Max Flow 100psi Max Pressure and Hytrel Diaphragm for Automotive Industry
Manufacturing Advantages
Plastic Diaphragm Pump with 15gpm Max Flow 100psi Max Pressure and Hytrel Diaphragm for Automotive Industry
Advanced manufacturing capabilities with precision engineering and quality assurance processes.
Packaging & Delivery
Plastic Diaphragm Pump with 15gpm Max Flow 100psi Max Pressure and Hytrel Diaphragm for Automotive Industry Plastic Diaphragm Pump with 15gpm Max Flow 100psi Max Pressure and Hytrel Diaphragm for Automotive Industry Plastic Diaphragm Pump with 15gpm Max Flow 100psi Max Pressure and Hytrel Diaphragm for Automotive Industry Plastic Diaphragm Pump with 15gpm Max Flow 100psi Max Pressure and Hytrel Diaphragm for Automotive Industry
Company Profile
Plastic Diaphragm Pump with 15gpm Max Flow 100psi Max Pressure and Hytrel Diaphragm for Automotive Industry
Company Introduction
Jiangliang Technology Co., Ltd is headquartered in Shanyang Town, Jinshan District of Shanghai, with 2 production bases and 3 branches in mainland China. Shanghai Jianglang has been awarded as High-Tech Enterprise and Credit Company title in consecutive years.
Technical Capabilities
We have strong capability of design, innovation, precision production and tight cooperation with Shanghai universities. Our main products are diaphragm pumps and control valves, including: Pneumatic Diaphragm Pump, Electric Diaphragm Pump, Piston Pump, Powder Pump, Sanitary Pump, Diaphragm Pump with Leakage Detector Controller, Pneumatic Diaphragm Regulating Valve, Control Valve, Sequencing Valve and related products.
Quality Certifications
The pumps and valves have been granted more than 40 patents, including 10 invention patents. Shanghai Jianglang participated in setting norms and standards for technical specification for pneumatic diaphragm pumps in petrochemical industry, according to the national standard No.: SH/T 3191-2017. Besides, Shanghai Jianglang obtains necessary certificates such as TS.A National Manufacturing License, CE, ATex, ISO9001, SGS and other certificates.
Industry Applications
Shanghai Jianglang mainly provides services and solutions for chemical industry, painting & coating industry, water treatment industry, petroleum industry, environmental protection industry and food and Pharmaceutical industry.
Global Reach
Shanghai Jianglang has established long term business relationship with famous enterprises such as BASF, Bayer, SAMSUNG etc. Its RV pneumatic diaphragm pump has been exported to more than 70 countries and regions.
Material Options
We have the following materials available, and our engineers will select the most suitable and economical material for you according to your specific working conditions.
  • Wetted parts material: PP, PVDF, Acetal, Aluminum alloy, Ductile iron, stainless steel, etc.
  • Diaphragm material: Teflon, Santoprene, Viton, Hytrel, Buna-N, etc.
Connection Types
Available inlet/outlet size: 1/4", 3/8", 1/2", 3/4", 1", 1-1/2", 2", 3"
  • Threaded connection: Plastic pumps from 1/4" to 1-1/2", and all metal pumps
  • Flanged connection: Plastic pumps from 1/2" to 3"
Customer Service
Plastic Diaphragm Pump with 15gpm Max Flow 100psi Max Pressure and Hytrel Diaphragm for Automotive Industry
  • All enquiries will be replied within 24 working hours
  • Professional pump producer with dedicated design team
  • All goods are packed with standard export wooden case (non-fumigation)
  • Fast after-sales service and technical support
Frequently Asked Questions
Q: What is MOQ?
A: 1 pc for regular product. Samples are available and sample cost can be deducted from future orders.
Q: What's the payment?
A: D/P, T/T, Western Union, please confirm with us with exact order.
Q: What is the delivery time?
A: Depend on the quantity. Generally speaking, 1-7 working days.
Q: What about package?
A: Cartons with foam inside & wooden case & Pallet.
Q: How are the products delivered to us?
A: By International express or Sea.
Q: How long is the warranty?
A: 15 years warranty for air motor, 5 years for pump body.
Q: Whether the products can be made of different standard?
A: Of course yes. We could produce product according to custom need.
