Specifications
Brand Name :
RUYA
Certification :
ISO 9001
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
≤3 sets， 3 months
Delivery Time :
2-3 months
Packaging Details :
wooden box
Load Weight :
30Kg
Table Diameter :
Ф300mm
Table Flatness :
0.02mm
Table Runout :
0.02mm
Rotary Accuracy :
±2″
Positioning Error :
±2″
Positioning Repeatability :
±2″
Rate Range :
±0.0001°/s~±500°/s
Description

1 Axis Electric Rate Position Table Single-axis Inertial Navigation Test Turntable


Product Description


The single-axis electric turntable is a special precision equipment with functions such as rate, position and swing, developed for the research testing, production debugging, testing and calibration of fiber optic gyroscopes and IMUs. It has stable performance, reliable operation, simple operation, easy portability, low cost and other characteristics. The equipment can also be used for experimental testing of other inertial components and units.


Product Parameters


Specification

1

Load Weight

30Kg

2

Table Diameter

Ф300mm

3

Table Flatness

0.02mm

4

Table Runout

0.02mm

5

Rotary Accuracy Of Axis

±2″

6

Positioning Error Of Angular Position

±2″

7

Positioning Repeatability Of Angular Position

±2″

8

Rate Range

±0.0001°/s~±500°/s；

9

Rate Accuracy

ω≤1°/s , 2×10-3 (1° average)

1°/s≤ω<10°/s , 2×10-4 (10° average)

ω≥10°/s , 2×10-5 (360° average)

10

Maximum Angular Acceleration

≥100°/s²
