2FT 4FT 20W 46W Tunable 3CCT Led Linear Strip Batten Light for Office Lifetime H 50
2FT 4FT 20W 46W Tunable 3CCT Led Linear Strip Batten Light for Office Lifetime H 50
2FT 4FT 20W 46W Tunable 3CCT Led Linear Strip Batten Light for Office Lifetime H 50
2FT 4FT 20W 46W Tunable 3CCT Led Linear Strip Batten Light for Office Lifetime H 50
2FT 4FT 20W 46W Tunable 3CCT Led Linear Strip Batten Light for Office Lifetime H 50
2FT 4FT 20W 46W Tunable 3CCT Led Linear Strip Batten Light for Office Lifetime H 50
2FT 4FT 20W 46W Tunable 3CCT Led Linear Strip Batten Light for Office Lifetime H 50
2FT 4FT 20W 46W Tunable 3CCT Led Linear Strip Batten Light for Office Lifetime H 50
2FT 4FT 20W 46W Tunable 3CCT Led Linear Strip Batten Light for Office Lifetime H 50
2FT 4FT 20W 46W Tunable 3CCT Led Linear Strip Batten Light for Office Lifetime H 50
2FT 4FT 20W 46W Tunable 3CCT Led Linear Strip Batten Light for Office Lifetime H 50
2FT 4FT 20W 46W Tunable 3CCT Led Linear Strip Batten Light for Office Lifetime H 50
Specifications
Color Temperature(CCT) :
4100K (Neutral White)
Lamp Luminous Efficiency(lm/w) :
130
Color Rendering Index(Ra) :
80
Support Dimmer :
Yes
Lifespan (hours) :
50000
Working Time (hours) :
50000
Product Weight（kg） :
2
Lighting solutions service :
Lighting and circuitry design, DIALux evo layout, Agi32 layout, auto CAD layout, Onsite metering, Project Installation
Light Source :
LED
CRI (Ra>) :
80
IP Rating :
IP65
Warranty(Year) :
5-Year
Place of Origin :
Jiangsu, China
Model Number :
RG-2LS20WD3CCT
Brand Name :
ILEDING
Input Voltage(V) :
AC 110V ( ± 10%)
Working Lifetime(Hour) :
50000
Lamp Luminous Flux(lm) :
130
Product Name :
Supermarket Office Led Linear Strip Batten Light 2FT 4FT 20W 46W
CRI :
80
Color Temp. :
3500K/ 4000K /5000K
Lifetime(H) :
50,000
Color Consistency :
Proprietary binning for uniform color
Power Factor :
0.99
Input voltage :
120-277V standard (120-347V for option)
Housing :
Plastic
Mounting :
Ceiling Mount or Cable Mount
Humidity :
20%-85% , non-condensing
MOQ :
2 pieces
Price :
$15.50/pieces 2-99 pieces
Description
Product Description

2FT 4FT 20W 46W Tunable 3CCT Led Linear Strip Batten Light for Office Lifetime H 50

2FT 4FT 20W 46W Tunable 3CCT Led Linear Strip Batten Light for Office Lifetime H 50

2FT 4FT 20W 46W Tunable 3CCT Led Linear Strip Batten Light for Office Lifetime H 50

LED Linear Strip Fixture

Overview
ILEDING’s Linear Strips Light Ideal choice for residential, commercial and industrial lighting. Steady performance and long lifetime
Features
•Voltage:120-277V/60Hz, 120-347V/60Hz as optional;
•High Lumen Efficiency:Lumen output more than 130 lm/w, reduces energy consumption up to 80% compared to a fluorescent fixture.
•CCT: 3500, 4000 and 5000K
3CCT: One fixture 3 color temp(3500K,4000K,5000K)
•Mounting method:Ceiling Mount or Cable Mount.
•Linkable (4FT to 8FT):need extra spare parts;
•Certified by DLC premium& ETL(cETL)
•Guarantee: 5 year warranty

Model Selection(Remark: Single Color(3500K/4000K/5000K is optional)

Model No. Product Size Rated Power Lumen CCT Effici ency Dimming
RG-2LS20WD3CCT 23.54”*2.62”*2.7” 20W 3250 3500K 130 0-10V Dimmable
RG-4LS25WD3CCT 47.24”*2.62”*2.7” 25W 3250 4000K
RG-4LS32WD3CCT 47.24”*2.62”*2.7” 32W 4160 5000K
RG-4LS35WD3CCT 47.24”*2.62”*2.7” 35W 4550 in one fixture
RG-4LS40WD3CCT 47.24”*2.62”*2.7” 40W 5200
RG-4LS46WD3CCT 47.24”*2.62”*2.7” 46W 5980

Drawing

2FT 4FT 20W 46W Tunable 3CCT Led Linear Strip Batten Light for Office Lifetime H 50

Specifications

Item specification Model
RG-2LS20WD3CCT RG-4LS25WD3CCT RG-4LS32WD3CCT RG-4LS46WD3CCT
General Performance Power Consumption 20W 25W 32W 46W
Lumens Delivered 2600lm 3250lm 4160lm 5980lm
Efficacy(lm/w) 130
CRI 80
Color Temperature 3500K/ 4000K /5000K
Lifetime(hours) 50000
Color Consistency Proprietary binning for uniform color
Power Factor 0.99
Input voltage 120-277V standard (120-347V for option)
Physical Housing Plastic
Mounting Ceiling Mount or Cable Mount
Humidity 20%-85% RH, non-condensing
Certification Certification ETL, cETL, DLC premium, LM-79, LM-80(LED),
Material usage RoHS compliant; no mercury
Work Temperature -4°F to 122°F (-20°C to +50°C) operating temperature
Environment Damp-listed
Warranty 5 years limited

Motion Sensor

2FT 4FT 20W 46W Tunable 3CCT Led Linear Strip Batten Light for Office Lifetime H 50 2FT 4FT 20W 46W Tunable 3CCT Led Linear Strip Batten Light for Office Lifetime H 50

Built-in motion sensor

120-277V Only, 5m Height Max

Built-in motion sensor

Suit for 120-347V, 4m Height Max

Shipping information

Type Pc/inner Pcs/Carton Carton Dimension (mm) 20GP 40GP 40HQ
2FT/20W 1pc 6pcs 635*255*185 5800pcs 11500pcs 14000pcs
4FT/25W,32W,35W,40W,46W 1pc 6pcs 1170*255*185 3150pcs 6200pcs 7200pcs
