Specifications
Brand Name :
Shanghai ileding
Model Number :
R5-4VTM46WD(HV1)3P-3CK
Place of Origin :
China
Certification :
ETL, DLC, NSF
MOQ :
100pcs
Price :
22-25USD
Supply Ability :
100000pcs / month
Delivery Time :
30-60 days
Packaging Details :
inner box + outer box
Mount :
Surface Mounted & Suspended As Standard; Angle Brackets, Tamper Proof Brackets Or Junction Box Bracket Optional
Housing Material :
Polycarbonate (PC)
IP Rating :
IP66
CRI (Ra) :
>80
Dimmable :
0-10V Dimming
Flame Resistance :
5VA
Beam Angle :
110°
Service Life :
50.000 H
Description

Product Description:

With a flame resistance rating of 5VA, this LED tri-proof light is the ideal choice for areas where fire safety is a concern. It is designed to resist the spread of flames and is constructed with high-quality materials that can withstand exposure to high heat without compromising performance or safety.

Whether you're working in extreme cold or hot temperatures, this LED tri-proof light is built to handle it all. It has a working temperature range of -40˚C to +40°C (-40˚F to +104°F), making it suitable for use in a wide range of environments and applications.

In addition to its durability and safety features, the LED tri-proof light is also designed to be highly energy-efficient. It has a power factor of >0.9, which means that it consumes less energy than traditional lighting solutions while still providing bright, clear illumination.

The LED tri-proof light is also dimmable, with 0-10V dimming capabilities that allow you to adjust the lighting level to your specific needs. This makes it a versatile solution that can be used in a variety of settings, from warehouses and factories to parking garages and outdoor spaces.

The input voltage for this LED tri-proof light is available in two options: HV1 = 120~347V or Blank = 120~277V. This gives you the flexibility to choose the voltage that best suits your needs and ensures that the light will operate reliably and efficiently.

Overall, the LED Tri-Proof Light is an excellent choice for anyone looking for a durable, reliable, and energy-efficient lighting solution. Whether you're working in a commercial or industrial setting, this light is built to last and provide the bright, clear illumination you need to get the job done.

Features:

  • Product Name: LED Vapor Tight Light
  • Dimmable: 0-10V Dimming
  • Auxiliary Output: 12V
  • Working Temp.: -40˚C~+40°C / -40˚F~+104°F
  • Surge Protection: 2.5KV
  • Beam Angle: 110°

Get the ultimate lighting solution with our LED tri-proof light. With features including dimmable 0-10V dimming, auxiliary output of 12V, and a working temperature range of -40˚C~+40°C / -40˚F~+104°F, our LED tri-proof light is perfect for any environment. Experience unparalleled surge protection with 2.5KV and a wide beam angle of 110°. Choose our LED tri-proof light for reliable and efficient lighting.

Technical Parameters:

Technical Parameter Description
Product Name LED Tri-proof Light
Input Voltage HV1 = 120~347V, Blank = 120~277V
Nominal Frequency 50/60Hz
Beam Angle 110°
IP Rating IP66
Flame Resistance 5VA
Impact Resistance IK10
Surge Protection 2.5KV
Light Source SMD2835
Lens Material Polycarbonate (PC)
Package 1pcs Per Inner Box, 4pcs Per Master Box For 2 Ft & 4ft; 1pcs Per Master Box For 8ft
