SINOTRUK HOWO Road Wrecker Truck Heavy Duty Rotator Tow Truck 8x4 35tons
SINOTRUK HOWO Road Wrecker Truck Heavy Duty Rotator Tow Truck 8x4 35tons
SINOTRUK HOWO Road Wrecker Truck Heavy Duty Rotator Tow Truck 8x4 35tons
SINOTRUK HOWO Road Wrecker Truck Heavy Duty Rotator Tow Truck 8x4 35tons
SINOTRUK HOWO Road Wrecker Truck Heavy Duty Rotator Tow Truck 8x4 35tons
SINOTRUK HOWO Road Wrecker Truck Heavy Duty Rotator Tow Truck 8x4 35tons
SINOTRUK HOWO Road Wrecker Truck Heavy Duty Rotator Tow Truck 8x4 35tons
SINOTRUK HOWO Road Wrecker Truck Heavy Duty Rotator Tow Truck 8x4 35tons
SINOTRUK HOWO Road Wrecker Truck Heavy Duty Rotator Tow Truck 8x4 35tons
SINOTRUK HOWO Road Wrecker Truck Heavy Duty Rotator Tow Truck 8x4 35tons
SINOTRUK HOWO Road Wrecker Truck Heavy Duty Rotator Tow Truck 8x4 35tons
SINOTRUK HOWO Road Wrecker Truck Heavy Duty Rotator Tow Truck 8x4 35tons
Specifications
Place of Origin :
Hubei, China
Brand Name :
SCS
Packaging Details :
Nude package
Supply Ability :
200 Unit/Units per Month
Price :
CN¥495,302.95/units >=1 units
Fuel Type :
Diesel
Emission Standard :
Euro 2
Condition :
New
Transmission Type :
Manual
Dimensions (L x W x H) (mm) :
11260*2500*3570
Product name :
rotator tow truck
Chassis brand :
Dongfeng Sinotruk Faw Bei Ben Tow
Driving type :
8*4
Usage :
Road Emergency Rescue
Warranty :
12 Months Guarantee
Certificate :
CCC ISO9001
Lifting weight :
20ton 30ton 40ton 50ton
Engine model :
WD615.47
Winch :
2*15 Tons KN
Color :
Customized
Port :
shanghai/tianjin/wuhan/shenzhen
Description
Product Description

SINOTRUK HOWO Road Wrecker Truck Heavy Duty Rotator Tow Truck 8x4 35tonsSINOTRUK HOWO Road Wrecker Truck Heavy Duty Rotator Tow Truck 8x4 35tonsSINOTRUK HOWO Road Wrecker Truck Heavy Duty Rotator Tow Truck 8x4 35tonsSINOTRUK HOWO Road Wrecker Truck Heavy Duty Rotator Tow Truck 8x4 35tons

Cabin

A/C installed,2~3 persons,LHD,electric window

Model

SCS5380TQZZDZ

No load(kg)

Curb Weight

32070

Front axle

9 TONS

Rear axle(double)

16 TONS

Full load

Max. Overall Weight

38000

Overall Dimensions(mm)

Length

11260

Width

2500

Height

3570

Wheel base(mm)

1800+4600+1350

Driving Model

8*4

Tyre

12.00R20

Engine

Model

WD615.47

Power(kw)

273

Displacement(mL)

9726

Transmission

HW19710,10forwards&1 reverses

Wrecker Equipment

Max. Towing Weight(kg)

30000

Lifting System

Max. Lifting Weight(kg)

10000

Max. Lifting Weight under all extension(kg)

8000

Lifting Weight in Situ(kg)

18000

Max. Ground Distance(mm)

900

Hoisting System

Max. Hoisting Weight(kg)

18000

Max. Hoisting Weight under all extension(kg)

8000

Extension Distance of Oil Cylinder(mm)

6000

Length of crane Arm(mm)

8470

Max. Hoisting Height(mm)

6500

Winch

No.

2

Curb Traction/Per(KN)

150

DN of Steel Rope(mm)

Φ20

Length of Steel Rope(m)

40*2

Min. Line Speed(m/min)

5

Outrigger

No.

2

Outrigger Span(mm)

1440

Landing Strength(KN)

80*2

Crane

360°rotate

Lifting Forks

5 pairs

Lifting fork base

1 pair

Jump-start cables

12~24 Volts

Electric system

Rear working lamp(stop,tail,turning)

3

Revolving beacon

1

Lamps for license plate/warning lamp

1 set

Pneumatic hoses

1 set
