Dimension and mass | Tire and rim |
| |
Overall dimensionL×W×H(mm) | 4850×1770×2100 | Tire type | 175R14LT |
Carriage dimension(mm) | 2550×1600×360 | Appearance |
|
Wheel base(mm) | 2700/3050 | Headlamp | Luxury single lamp |
Tread(F/R)(mm) | 1400/1278 | Fog lamp(F/R) | Single rear fog lamp |
Curb weight(kg) | 1500 | Deafener | Tail decoration(none) |
G.V.W(kg) | 2490 | Bumper(F/R) | Front bumper |
Rated loading(kg) | 860 | windscreen wiper | Front window wiper |
Engine | Interior board | Light leather upholstery | |
Model | L4690-1AEB | Instrument | Mechanical with water temperature warning |
Displacement (ml) | 1809 | Seat | Light seat |
Cylinder-Bore × Stoke(mm) | 4-80×90 | No.of seat | 2 |
Type | 4-cylinder in line, 4-stroke, water cooling EGR, Diesel engine with electronic control fuel injection,turbocharging intercooling | Safety |
|
|
| Safety belt | Light three-point belt |
|
| Stereo |
|
Max.power(kw) | 40 | Stereo | FM Radio/MP3 |
Max.torque/Speed(N.m)(rpm) | 135/2000 | Painting |
|
Volume of oil tank(L) | 40 | Metal Painting |
|
Fuel consumption under limited condition(L/100Km) | 7 | Optional |
|
Type of gearbox | Dongfeng Manual 5 gears | Central lock |
|
Max.speed(km/h) | 80 | Air-conditioner |
|
Brake system | Double circuit hydraulic brake |
|
|
Drive mode | Rear Drive |
|
|
