Specifications
Transmission Type :
Manual
Condition :
New
Emission Standard :
Euro 6
Fuel Type :
Diesel
Dimensions (L x W x H) (mm) :
5998*2000*3050mm
Place of Origin :
Hubei, China
Brand Name :
FAW
After-sales Service Provided :
Onsite Installation, Video technical support, Field installation, commissioning and training, Online support
Horsepower :
< 150hp
Engine Capacity :
< 4L
Fuel Tank Capacity :
≤100L
Working height :
Customer's Requirement
COLOR :
Customer's Requirement
MOQ :
5 sets
Price :
CN¥92,552.96/sets 5-58 sets
Description

FAW Single-row Folding Arm Aerial Work Truck Work High Lift Operation Elevated Operation

Engine

Euro VIemission,95HP

Clutch

Reinforced diaphragm clutch, diameter 430mm

Breaks

Service brake: dual circuit compressed air brake

Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake

Steering Gear

power steering, hydraulic steering with power assistance

Tire

7.50R All steel radial tire

Working Platform

360°turning(left or right), H-shape legs 360°

Extendable boom section

2002/3/4

Max Lifting Weight

990KG 1000KG,1500KG,2000KG

Max. Working Radius

8m,10m,12m,13m,14m,15m,16m,17m,18m

Boom Type

Straight/fold-ability

Lifting Max. Height

8m,10m,12m,13.5m14m,16.5m,17.5m,18m,20m

The pentagon work arm, with synchronous telescoping, is compact in structure, high in operating efficiency and wide in operating range. Built in telescopic oil cylinder and steel wire telescopic mechanism make it easier to observe fault points and facilitate maintenance

Front X and rear H-shaped legs, fully enclosed, with good stability, can be operated simultaneously or separately, suitable for various working conditions
The landing leg operation box is equipped with lighting for convenient night work, and a vehicle level gauge is installed to
ensure vehicle level and safety
The left and right rotation of the hanging basket is driven by an electric motor, which is flexible, convenient, safe and reliable for operation
Computer control, automatic amplitude limiting, dangerous work alarm, excellent safety performance. Get off the car with a display that displays the working conditions of the entire vehicle in real time
Main supporting hydraulic and electrical components: load sensitive proportional valves, balance valves, controllers, etc. are all imported parts
