ISUZU Single Row Column Plate-type Cargo Truck Pick up Truck
ISUZU Single Row Column Plate-type Cargo Truck Pick up Truck
ISUZU Single Row Column Plate-type Cargo Truck Pick up Truck
ISUZU Single Row Column Plate-type Cargo Truck Pick up Truck
ISUZU Single Row Column Plate-type Cargo Truck Pick up Truck
ISUZU Single Row Column Plate-type Cargo Truck Pick up Truck
ISUZU Single Row Column Plate-type Cargo Truck Pick up Truck
ISUZU Single Row Column Plate-type Cargo Truck Pick up Truck
ISUZU Single Row Column Plate-type Cargo Truck Pick up Truck
ISUZU Single Row Column Plate-type Cargo Truck Pick up Truck
ISUZU Single Row Column Plate-type Cargo Truck Pick up Truck
ISUZU Single Row Column Plate-type Cargo Truck Pick up Truck
Specifications
Condition :
New
Steering :
Left
Emission Standard :
Euro 6
Brand Name :
ISUZU
Place of Origin :
Hubei, China
Segement :
Light truck
Market Segement :
Logistics transportation
Fuel Type :
Diesel
Engine Capacity :
< 4L
Cylinders :
4
Horsepower :
< 150hp
Transmission Type :
Manual
Forward Shift Number :
6
Reverse Shift Number :
1
Maximum Torque(Nm) :
≤500Nm
Cargo Tank Dimension :
4.2*2.1*0.4
Cargo Tank length :
≤4.2m
Cargo Tank Type :
Fence
Gross Vehicle Weight :
<=5000 kg
Capacity (Load) :
1 - 10t
Fuel Tank Capacity :
≤100L
Drive Wheel :
4X2
Passengers :
3
Driver's Seat :
Normal
Seat Rows :
Single row
Rear Camera :
Camera
ABS(Antilock Braking System) :
Yes
ESC(Electronic Stability Control System) :
None
Touch Screen :
None
Multimedia System :
Yes
Window :
Automatic
Tire Number :
6
After-sales Service Provided :
Onsite Installation, Video technical support, Field installation, commissioning and training, Online support
Color :
Customer's Request
Price :
CN¥97,614.45/sets 1-17 sets
Description

ISUZU Single Row Column Plate-type Cargo Truck Pick up Truck

ISUZU Single Row Column Plate-type Cargo Truck Pick up Truck

Announcement model: JXW1040CDJA2
Type: truck
Driving form: 4X2
Wheelbase: 3360mm
Case length level: 4.2 m
Engine: Jiangxi Isuzu 4JD25Q6H
Gearbox: 6-speed transmission
Rear axle speed ratio: 4.556
Body length: 5.995 meters
Body width: 2.19m
Body height: 2.36m
Front wheel base: 1680mm
Rear wheel base: 1570mm
Vehicle weight: 2.565 tons
Rated load: 1.8 tons
Total mass: 4.495 tons
Maximum speed: 100KM/h
Tonnage class: Light truck
Approach Angle: 20 degrees
Departure Angle: 16 degrees
Note: Optional: Speed ratio 5.286
Front/rear overhang: 1.09/1.545 m
Engine type: Jiangxi Isuzu 4JD25Q6H
Engine brand: Jiangxi Isuzu
Engine commonly known as: Jiangxi Isuzu 2.5L
Number of cylinders: 4-cylinder
Fuel Type: Diesel oil
Cylinder arrangement: orthostitial
Displacement: 2.478 L
Emission standard: e
Maximum output power: 112kw
Maximum horsepower: 152 horsepower
Container form: panel
Container length: 4.2 m
Container width: 2.1 m
Container height: 0.4 m
Cab width: 2050mm
Number of permitted passengers: Three people
Number of seats: Single row
Transmission model: 6-speed transmission
Shift mode: Manual operation
Forward gear: Sixth gear
Number of reversals: one
Tank capacity: 100L
Front axle allowable load: 1840KG
Rear axle allowable load: 2655KG
Speed Ratio: 4.556
Number of spring pieces: 3/5 + 2
Tire Specifications: 7.00R16LT 8PR,7.00R16LT 10PR
Number of tires: six
Vehicle brake type: Air brake
Parking brake: Cutoff brake
