Chassis model | HFC1030PX1 | |
Engine | ||
Model | HFC4GB3-3E | |
Description | In-line/4 cylinders/normally aspirated /water cooled/ electric control/VVT/gasoline engine | |
Rated power of engine (kw/HP) | 88/120 | |
Maximum torque (N.m@rpm) | 155@3500~4500RPM | |
Displacement (ml) | 1590 | |
Emission standard | Euro VI | |
Gearbox | ||
Description | MG70,manual,5 forward gears & 1 reverse gear | |
Front / Rear axle | ||
Front axle load (Kg) | 1255 | |
Rear axle load(Kg) | 2240 | |
Drive type | 4X2 | |
Type of tire | 175/75R16LT 8PR | |
Quantity of tires | 6+1 | |
F/R leaf spring | Non-independent suspension, with auxiliary leaf spring 3/3+2 | |
Brake system | Service brake type | Drum type,hydraulic pressure double loop braking |
ABS | Provided | |
Parking brake type | Energy storage spring rear wheel braking | |
Steering device | Left hand drive,power steering | |
Weight parameter | ||
Curb weight (Kg) | 1740 | |
Rated load capacity(Kg) | 1625 | |
Max. load capacity(Kg) | 3000 | |
Performance parameter | ||
Maximum speed (km/h) | 100 | |
Maximum grade ability (%) | ≥22% | |
Dimension parameters | ||
Overall dimensions (LxWxH)mm | 5180×1765×2600 | |
Internal van dimensions (LxWxH)mm | 3110×1650×1750 | |
Wheelbase (mm) | 2600 | |
Fuel tanker capacity | 75L | |
Cabin | Single row,metallic painting,sedan configuration,2 passengers allowable,adjustable steering wheel, power-assisted clutch,radio,USB+AUX,A/C,central lock,electric window,safety belt provided |
FAQ
Q:How about the warranty?
A:One year.
Q:Do you have ISO certificate?
A:Yes , we have,please contact us to get our certificates.
Q:How about the delivery time?
A: Most of our trucks have stock ,we can deliver to you within 7 days, if specially ordered , normally we need around 30 days for production.
Q: How many units of truck does your factory produce per year?
A:Almost 3000 units.Nearly 300units per month.
Q: How do you control the quality of product?
A:Our Factory has standard production workshop,gets ISO CCC BV certificates,our workers are well trained. Every unit of product undergoes a rigorous inspection process.
Q: How about your product after-sales service system?
A:Our main export countries have accepted after-sales
service,some countries use the third party service.
Q: Do you accept custom order? What’s is your MOQ order?
A:Yes, we do, our MOQ is 1 unit.
Q: What’s the payment terms?
A:By T/T or L/C at sight.
Q: How about shipment?
A:20FT container, 40FT container,40FT high container,
open-top container,flat bed container,Ro-Ro ship or bulk
ship according to the size the products.
If need more detailed information,please feel free to contact me.
