FORLAND 4X2 3 Ton Lorry Truck Dimensions
FORLAND 4X2 3 Ton Lorry Truck Dimensions
FORLAND 4X2 3 Ton Lorry Truck Dimensions
FORLAND 4X2 3 Ton Lorry Truck Dimensions
FORLAND 4X2 3 Ton Lorry Truck Dimensions
FORLAND 4X2 3 Ton Lorry Truck Dimensions
FORLAND 4X2 3 Ton Lorry Truck Dimensions
FORLAND 4X2 3 Ton Lorry Truck Dimensions
FORLAND 4X2 3 Ton Lorry Truck Dimensions
FORLAND 4X2 3 Ton Lorry Truck Dimensions
FORLAND 4X2 3 Ton Lorry Truck Dimensions
FORLAND 4X2 3 Ton Lorry Truck Dimensions
Specifications
Condition :
New
Steering :
Left
Emission Standard :
Euro 3
Brand Name :
Forland
Place of Origin :
Hubei, China
Segement :
Light truck
Market Segement :
Logistics transportation
Fuel Type :
Diesel
Engine Capacity :
4 - 6L
Cylinders :
4
Horsepower :
< 150hp
Transmission Type :
Manual
Forward Shift Number :
5
Maximum Torque(Nm) :
≤500Nm
Size :
5490*1930*2170
Cargo Tank Dimension :
3300x1610x360
Cargo Tank length :
≤4.2m
Cargo Tank Type :
Column plate
Gross Vehicle Weight :
4350
Capacity (Load) :
1 - 10t
Drive Wheel :
4X2
Passengers :
3
Seat Rows :
Single row
Rear Camera :
None
ABS(Antilock Braking System) :
None
ESC(Electronic Stability Control System) :
None
Touch Screen :
None
Air Conditioner :
Manual
Tire Number :
6
After-sales Service Provided :
Video technical support, Return and Replacement, Online support
Product name :
New light truck
Certificate :
CCC ISO
Wheelbase :
3360mm
Emission :
EURO 2/3/4/5
Loading capacity :
1-5Ton
Tire :
6.50-16
Warranty :
12 Months
Chassis brand :
FORLAND
Horse power :
57HP
Transmission :
Manual Transmission
Packaging Details :
nacked package
Port :
any port in China
Supply Ability :
200 Unit/Units per Month
Price :
CN¥50,470.29-54,230.25/units
Description

FORLAND 4X2 3 ton lorry truck dimensions

Product Description

Detailed Specifications
Category Light Cargo Truck Vehicle model BJ1042
Cabin D1695 Driving type 4X2
Inner dimensions of the cargo body (LxWxH)mm 3670×1810×360
Rated power(kw/rpm) 34.5/3000 Steering gear power steering
Wheels and tyre size 6.50-10 option Airconditioner/Warmer
Rated payload(kg) 1900 Curb Weight 2200
Basic equipment radio, spare tyre, adjustable, electrical controlled engine stop

Vehicle brand FORLAND
Cabin D1695
Whole vehicle main dimensions Overall dimensions (LxWxH)mm 5490×1930×2170
Inner dimensions of the cargo body (LxWxH)mm 3670×1810×360
Driving type 4x2
Wheel base (mm) 2800
Wheel track (front/rear) (mm) 1415/1435
Weight data Curb weight (kg) 2200
Rated payload (kg) 1900
Persons in cab (persons) 2
Gross vehicle weight(kg) 4350
Whole vehicle main performance Max. speed(km/h) 90
Max. slope of climb(%) ≥25
Engine Model 4B1-82C40
Type Four-cylinder, in-line,DI,diesel engine
Displacement(L) 2.27
Rated power(kw/rpm) 60/3200
Max torque (N.m/rpm) 123/1900-2100
Gearbox Model/Type 5-20
Clutch Type Φ254×Φ160 Diaphragm spring clutch
Rear axle Type/Main reducer ratio 130,Rate:5.833
Suspension Front suspension/Leaf spring number Non-independent,7
Rear suspension/Leaf spring number Non-independent,7+5
Steering gear Steering gear Type/Speed ratio Circular ball,Power steering
Brake system Service brake Hydraulic brake
Parking brake Central drup brake
Wheels and tyre size 6.50-16
Battery Rated voltage 24V
Basic equipment Heater,radio+MP3
QTY per 40'HQ 3
Detailed images

FORLAND 4X2 3 Ton Lorry Truck DimensionsFORLAND 4X2 3 Ton Lorry Truck Dimensions

FORLAND 4X2 3 Ton Lorry Truck Dimensions

FORLAND 4X2 3 Ton Lorry Truck Dimensions

FORLAND 4X2 3 Ton Lorry Truck Dimensions

FORLAND 4X2 3 Ton Lorry Truck Dimensions

FORLAND 4X2 3 Ton Lorry Truck Dimensions

FORLAND 4X2 3 Ton Lorry Truck Dimensions

Company Information

Company Information

Hubei Runli Special Automobile Co., Ltd. is located in Suizhou City, an automobile industry city in China and it covers an area of more than 100,000 square meters. Our company is a private enterprise which is approved by the Ministry of industry and information Technology of China, Ministry of commerce of China,and focused on high level design,safety,environmental protection,high efficiency,energy-saving,automation technology research and application,especially for product appearance,economics,function.

Company have set up sale service department in 32 province and has many dealers, we use direct sales and distribution model, builds a good long-term cooperation relationship with the major domestic oil and dangerous goods transport enterprise.The company has become the special automobile refitting base of Dongfeng, jiefang, Foton, Sinotruck, Shanxi Auto etc, and is the strategic partner with the Sinopec and Petro China.

The company was granted “Enterprise of observing contract and valuing credit” “customer satisfaction enterprise”and “AAA”credit of bank, “Great scientific and technical enterprise by Hubei government for many years. It is licensed by AQSIQ and is the only private enterprise which has got military quality system certification.

Factory Workshop

FORLAND 4X2 3 Ton Lorry Truck Dimensions

Certifications

FORLAND 4X2 3 Ton Lorry Truck Dimensions

Payment Terms

Our Payment Terms and Delivery time:

1. TT or LC AT SIGHT 30% down payment, 70% balance paid before shipment, all by T/T or by 100% LC at sight.

Min order: 1 unit

Delivery time: 15-20days after get the deposit or LC

Packing: nacked package, waxed before delivery by sea.

Documents: B/L, Commercial invoice, Packing list, Certificate of origin etc

Our Bank Information:

BENEFICIARY: HUBEI RUNLI SPECIAL AUTOMOBILE CO., LTD

Address: NO.77, century ave, suizhou city, hubei province
BANK OF BENEFICIARY: BANK OF CHINA, HUBEI BRANCH, SUIZHOU SUB BRANCH
ADDRESS OF BANK: NO.69 LIESHAN ROAD, SUIZHOU, HUBEI, CHINA
ACCOUNT NO.: 20310608092001
SWIFT NO.: BKCHCNBJ600

Our Company Main Products:

The main products are

1. Water truck

2. Fuel tanker truck, Oil Truck, Tanker Truck

3. Fire engine truck

4. Truck mounted with crane

5. Dump truck, tipper, heavy duty truck

6. LPG Tank Truck, LPG Truck, LPG Tanker, LPG Semi-trailer, LPG Storage Tanker

7. Bulk cement truck

8. Concrete mixer truck, mixer truck, cement mixer truck

9. Garbage truck, Self-loading garbage truck, garbage compactor truck,sealed garbage truck

10. Fecal suction truck, sewage suction truck

11. High altitude working truck

12. Chemical liquid truck

13. Van truck, insulated truck, refrigeration truck

14. Semi trailer, Low plate semi-trailer, oil semi-trailer, van semi-trailer, bulk cement transportation semi-trailer, container semi-trailer, chemical liquid semi-trailer,etc more than 300 types in total.

More information,please contact with Oversea Market Sales Manager:

More specs , photos, price, delivery time and other need,

please contact with Kilen.

Hotline(whatsapp): 0086 155 8688 7678

QQ number: 676459215 Skype:kilen.automobile

Welcome to visit our company! Suizhou city, Hubei Province.
