Product brand | JMC | ||
Cabin / Passenger capacity | New model T822, single row, luxury configuration, 2 passengers + 1driver,front lifting,Central locking, remote control key, power steering, air conditioning, ABS,Bluetooth music / Bluetooth phone ,Driver armrest ,Driver overhead storage box ,Overhead storage box mounted USB port | ||
Chassis | Model | JX1044 | |
Overall dimensions | 5990x2160x3085mm (L*W*H) | ||
PTC | 3490KG | ||
TARE | 2450KG | ||
Drive type | 4x2 | ||
F/R suspension | 1115/1515 | ||
Wheelbase | 3360mm | ||
Number of axles | 2 | ||
Axle-load | 2600/4400kgs(one rear driving axle) | ||
Number of leaf spring | 3/5+3 | ||
F/R track | 1615/1570mm | ||
Tire | 6+1pcs, 7.0R16 10PR | ||
Max speed | 110 km/h | ||
Brake system | Exhaust Brake , ABS | ||
Steering | Left hand drive with power steering | ||
Transmission | 5MT,mechanical,5 forward + 1 reverse gears | ||
Engine | Engine model | JX493ZQ4A (Euro 2) | |
Max.power | 68KW(92HP) | ||
Description | In line,water cooled,four strokes,turbo charged,inter cooled,direct injection,diesel engine (lSUZU technology) | ||
Rated revolution | 3600rpm | ||
Max torque | 220N.m@1800-2000rpm | ||
Exhaust | 2771ml | ||
Fuel Tank Capacity (L) | 105 | ||
Van body | Dimension | 4100x1780x1780mm (L*W*H) | |
Material | Corrugated steel | ||
Painting | Description | With sand blasting, painted with epoxy paint,finished color | |
Warranty | Year | 1 |
