SINOTRUK Single Row Van Truck Freight Train Wagon Deliver Truck
SINOTRUK Single Row Van Truck Freight Train Wagon Deliver Truck
SINOTRUK Single Row Van Truck Freight Train Wagon Deliver Truck
SINOTRUK Single Row Van Truck Freight Train Wagon Deliver Truck
SINOTRUK Single Row Van Truck Freight Train Wagon Deliver Truck
SINOTRUK Single Row Van Truck Freight Train Wagon Deliver Truck
SINOTRUK Single Row Van Truck Freight Train Wagon Deliver Truck
SINOTRUK Single Row Van Truck Freight Train Wagon Deliver Truck
SINOTRUK Single Row Van Truck Freight Train Wagon Deliver Truck
SINOTRUK Single Row Van Truck Freight Train Wagon Deliver Truck
SINOTRUK Single Row Van Truck Freight Train Wagon Deliver Truck
SINOTRUK Single Row Van Truck Freight Train Wagon Deliver Truck
Specifications
Condition :
New
Steering :
Left
Emission Standard :
Euro 6
Brand Name :
SINOTRUK
Place of Origin :
Hubei, China
Segement :
Light truck
Market Segement :
Logistics transportation
Fuel Type :
Diesel
Engine Capacity :
< 4L
Cylinders :
4
Horsepower :
< 150hp
Transmission Type :
Manual
Forward Shift Number :
5
Reverse Shift Number :
1
Maximum Torque(Nm) :
≤500Nm
Cargo Tank Dimension :
4.15*2.1*2.3
Cargo Tank length :
≤4.2m
Cargo Tank Type :
Van
Gross Vehicle Weight :
<=5000 kg
Fuel Tank Capacity :
≤100L
Drive Wheel :
4X2
Passengers :
3
Driver's Seat :
Normal
Seat Rows :
Single row
Rear Camera :
Camera
ABS(Antilock Braking System) :
Yes
ESC(Electronic Stability Control System) :
None
Touch Screen :
None
After-sales Service Provided :
Onsite Installation, Video technical support, Field installation, commissioning and training, Online support
Color :
Customer's Request
Price :
CN¥86,768.40/sets 1-17 sets
Description

SINOTRUK Single Row Van Truck Freight Train Wagon Deliver Truck

Announcement model: ZZ5047XXYF3115F145H
Type: A van
Driving form: 4X2
Wheelbase: 3280mm
Case length level: 4.2 m
Engine: Weichai WP2.3Q140E62
Gearbox: Wan Li Yang WLY5G32
Body length: 5.99 m
Body width: 2.17m
Body height: 3.35m
Front wheel base: 1640mm
Rear wheel base: 1530mm
Vehicle weight: 2.8 tons
Rated load: 1.495 tons
Total mass: 4.49 tons
Maximum speed: 95KM/h
Tonnage class: Light truck
Approach Angle: 18 degrees
Departure Angle: 17 degrees
Front/rear overhang: 1.16/1.55 m
Engine type: Weichai WP2.3Q140E62
Engine brand: Weichai
Engine commonly known as: Weichai WP2.3Q
Number of cylinders: 4-cylinder
Fuel Type: Diesel oil
Cylinder arrangement: orthostitial
Displacement: 2.289 L
Emission standard: Kokuroku
Maximum output power: 103kw
Maximum horsepower: 140 horsepower
Maximum torque: 320N·m
Maximum torque speed: 1600-2400RPM
Rated speed: 3200RPM
Engine form: High pressure common rail
Engine oil change cycle: 50,000 km
Container form: Van type
Container length: 4.15 m
Container width: 2.1 m
Container height: 2.3 m
Number of permitted passengers: Three people
Number of seats: Single row
Transmission model: Wan Li Yang WLY5G32
Shift mode: Manual operation
Forward gear: Fifth gear
Number of reversals: one
Front axle allowable load: 1790KG
Rear axle allowable load: 2700KG
Number of spring pieces: 3/5 + 3
Tire Specifications: 7.00R16LT 10PR
Number of tires: six
Vehicle brake type: Air brake
Parking brake: Cutoff brake
Engine braking: In-cylinder braking
Front wheel brake: Standard drum brake, optional disc brake
Rear wheel brake: Drum brake
