HOWO Fire Sprinkler Truck Ladder Fire Truck Aerial Platform Fire Engine
HOWO Fire Sprinkler Truck Ladder Fire Truck Aerial Platform Fire Engine
HOWO Fire Sprinkler Truck Ladder Fire Truck Aerial Platform Fire Engine
HOWO Fire Sprinkler Truck Ladder Fire Truck Aerial Platform Fire Engine
HOWO Fire Sprinkler Truck Ladder Fire Truck Aerial Platform Fire Engine
HOWO Fire Sprinkler Truck Ladder Fire Truck Aerial Platform Fire Engine
HOWO Fire Sprinkler Truck Ladder Fire Truck Aerial Platform Fire Engine
HOWO Fire Sprinkler Truck Ladder Fire Truck Aerial Platform Fire Engine
HOWO Fire Sprinkler Truck Ladder Fire Truck Aerial Platform Fire Engine
HOWO Fire Sprinkler Truck Ladder Fire Truck Aerial Platform Fire Engine
HOWO Fire Sprinkler Truck Ladder Fire Truck Aerial Platform Fire Engine
HOWO Fire Sprinkler Truck Ladder Fire Truck Aerial Platform Fire Engine
Specifications
Drive Wheel :
6x4
Type :
RESCUe
Transmission Type :
Manual
Condition :
New
Horsepower :
351 - 450hp
Tank Capacity :
7001 - 10000L
Fuel Type :
Diesel
Size :
10550*2550*3750
Place of Origin :
Hubei, China
Brand Name :
Sinotruk Howo
Color :
Customer's Requirements
Steering wheel :
Customer's Requirements
Price :
CN¥303,689.40/units 1-17 units
Description

HOWO Fire Sprinkler Truck Ladder Fire Truck Aerial Platform Fire Engine

32 meters lift jet fire truck

32m High Lift Jet Fire Truck
Vehicle Basic Parameters
Water Tank 7000 liters
Chassis brand & Year SINOTRUK HOWO, 2018 new
Wheel Drive 6x4,LHD
Overall Dimension 10550x2550x3750mm
Gross Weight 33800kg
Curb Weight 24300kg
Load capacity 12020kg
Engine SINOTRUK WD615.38,380HP 6-cyl 9726cc Turbocharged Intercooled
Fuel Type Diesel
Wheelbase 4600+1400mm
Tires: 10+1, 295/80R22.5
Cabin Double cab, 2+4 seats
Transmission Manual, 10 front gears and 2 rear gear
Brake Full air brake
Max Speed 90km/h
High Lift Arm Jetting System
Arm lifting height 32meters
Type Hydraulic 2 section arm
Nozzle High pressure water jet nozzle
Other With camera
Pump
Model CB10/100
Flow 100L/s
Pressure 1.0MPa
Water diversion time <80s
Water suction depth 7m
Water Tank
Volume 7000 liters
Material stainless steel304
Manhole One unit
Flow valve One unit
Fire Monitor(shooting nozzle)
Model PS50 water jet nozzle
Pressure pump 1.0MPa
Flow 64L/s
Range >75m
Rotation angle 355 horizontal
Other Config.
Fire pump compartment One unit, with three sets aluminum shutter doors
Fire tool compartment 2sets, aluminum shutter doors
Fire tool 21 sets
Lighting light One unit, at rear top of truck
Side warning light 8pcs
Spare tire One unit
Water suction hose 2 pcs, 6m long ruber hose per pcs
Ladder One set
User manual One pcs
Reflective stickers Factory standard
Logo painting & Color Customzied
