Dimension(L×W ×H)(unloaded)(mm) | 8750×2550×3450 | ||
Cargo body size (L×W×H)(mm) | 5800*2300*1200+300mm | ||
Approaching angle/Departure angle(°) | 19/21 | ||
Overhang(front/rear) (mm) | 1430/2095 | ||
Wheel base (mm) | 3800+1350 | ||
Max speed(km/h) | 78 | ||
Front Axle Weight(kg) | 9500(Kg) | ||
Rear Axle Weight(kg) | 16000*2(Kg) | ||
Actual loading(kg) | 30000-60000 | ||
Engine (made in China) | Model | WP10.380E22 | |
Fuel type | Diesel | ||
Displacement (ml) Power(kw) | 9726 279 | ||
Emission | EURO 2 | ||
Fuel tanker capacity (L) | 400L | ||
Transmission | Model | HW19712,12 forward&2 reverse | |
Brake system 制动系统 | Service brake | Dual circuit compressed air brake | |
Parking brake | spring energy, compressed air operating on rear wheels | ||
Steering system | Model型 | LHD | |
Front axle | Steering with double T-cross section beam | ||
Rear axle | Cast axle housing, central double reduction with differential locks between axles and wheels | ||
Electrical system | Battery | 2X12V/180Ah | |
Alternator | 28V-1500kw | ||
Starter | 7.5Kw/24V | ||
other | Dual warning lights in the cab, |
