Specifications
Place of Origin :
Hubei, China
Brand Name :
Runzhixing
Medium :
Crude oil, methanol
Tank Volume :
19.9cbm
Chassis :
Dongfeng, EQ1268GSZ6DJ
Engine :
YUCHAI, YC6S06 245-60
Transmission :
FAST, 8JS95
Wheelbase :
1995+4200 MM
Tire :
295/80R22.5 18PR, vacuum tire
Front Axle :
3.6 t
Rear Axle :
10 t
Emission Standard :
Euro 6
Price :
CN¥296,458.70/units >=1 units
Description
Product Description

Overall Dimensions (mm)

10300x2550x3650

Cab

Brand

Dongfeng Jincheng

Capacity (people)

2/3

Position of Driver

LHD

(Left hand drive)

Chassis

Engine

Brand

YUCHAI

Model Number

YC6S06 245-60

Displacement (ml)

6234

Fuel Type

Diesel oil

Power (kw/ps)

180/245

Emission Standard

Euro 6

Transmission

Brand

FAST

Model number

8JS95

Type

8MT, 8 forward & 2 reverse gears

Wheelbase (mm)

1995+4200

Axle

Number

3

Tire

Drive type

6x2

Amount & Distribution

8

(4 tires in the front, 4 tires on the back)

Specification

295/80R22.5 18PR vacuum tire, with a spare tire

Approach Angle (°)

29

Departure Angle (°)

10

Front Overhang (mm)

1475

Rear Overhang (mm)

2530

Tank

Material

Q235 carbon steel

Dimensions (mm)

7200×2380×1580

Nominal Capacity (L)

19900

Actual Capacity (L)

18980

Weight

Gross Weight (kg)

25500

Rated Load (kg)

15065

Curb Weight (kg)

10305
Safety Devices

1. Tire blowout emergency handling device

2. Front collision warning system

3. Lane straying warning system

4. ABS

5. Speed limiter

6. Front disc/rear drum brake

7. front-installed exhaust pipe

Standard Chassis Configuration 1. Central control lock

2. Original A/C

3. Electricity-driven window glass

4. Air braking

5. Air-cut brake

6. Power steering

7. Clutch steering

8. Air horn

Standard

Superstructure Configuration

The tank is made of Q235 carbon steel, and is equipped with aluminum alloy manhole, aluminum alloy subsea valve, subsea valve sound and light alarm, emergency shutoff valve, vehicle-mounted copper gear pump(capable of pumping in and out), rear ladder, folding guardrails at both sides on the top of the tank, two fire extinguishers, two oil pipes with the same length as the pipe box and quick connector, silver gray tank color, reflective tape,reflective strip, reflective plate, reflective sign, two ordinary tank mouths, safety valve bursting disk.

Factory Direct Price Dongfeng Jincheng 6x2 19.9cbm Flammable Fluid Methanol Crude Oil Chemical Tank TruckFactory Direct Price Dongfeng Jincheng 6x2 19.9cbm Flammable Fluid Methanol Crude Oil Chemical Tank TruckFactory Direct Price Dongfeng Jincheng 6x2 19.9cbm Flammable Fluid Methanol Crude Oil Chemical Tank TruckFactory Direct Price Dongfeng Jincheng 6x2 19.9cbm Flammable Fluid Methanol Crude Oil Chemical Tank TruckFactory Direct Price Dongfeng Jincheng 6x2 19.9cbm Flammable Fluid Methanol Crude Oil Chemical Tank TruckFactory Direct Price Dongfeng Jincheng 6x2 19.9cbm Flammable Fluid Methanol Crude Oil Chemical Tank TruckFactory Direct Price Dongfeng Jincheng 6x2 19.9cbm Flammable Fluid Methanol Crude Oil Chemical Tank Truck

Packaging & Shipping

Packaging

- Naked or waxed.

-->Container (20GP, 40GP, 40HQ, 40FR).

-->Ro-Ro shipping.

-->Bulk ship.

-->Flat rack.

etc.

Shipping

- By sea or by rail, at customer request.

Services

1. Warranty period: 1 year since our customer receives his products.

2. Necessary documents: Operation manuals and guiding videos.

3. Troubleshooting: If any questions about operation arises, contact us to resolve your problems.

Factory profile

Honorary certificate

Factory Direct Price Dongfeng Jincheng 6x2 19.9cbm Flammable Fluid Methanol Crude Oil Chemical Tank Truck

Factory snapshots

Factory Direct Price Dongfeng Jincheng 6x2 19.9cbm Flammable Fluid Methanol Crude Oil Chemical Tank TruckFactory Direct Price Dongfeng Jincheng 6x2 19.9cbm Flammable Fluid Methanol Crude Oil Chemical Tank Truck

Factory Direct Price Dongfeng Jincheng 6x2 19.9cbm Flammable Fluid Methanol Crude Oil Chemical Tank Truck

Factory Direct Price Dongfeng Jincheng 6x2 19.9cbm Flammable Fluid Methanol Crude Oil Chemical Tank Truck

Product delivery ceremony (China customers)

Factory Direct Price Dongfeng Jincheng 6x2 19.9cbm Flammable Fluid Methanol Crude Oil Chemical Tank Truck

Introduction to our factory

Hubei Runli Special Automobile Co., Ltd is established on January 19th, 2009, and its registered capital is 5,000.00 million CNY. Our company is permitted by China Ministry of Industry and Information Technology to produce special automobile and hazardous chemicals tank body. Besides, our company is credited with such titles as “Little Giant for Specialized,Precise,Unique and Innovative Automobile Production”,“China High-tech Enterprise”,“Enterprise With Excellent Credit Standing (Hubei province, China)”,“Provincial Enterprise Technology Center (Hubei province, China)” and “Special Automobile Export Enterprise (Hubei province, China)”.

Our factory covers an area of 120000 square meters, and has the capacity of producing 5,000 special automobiles each year. There are 5 major types of products we concentrate on manufacturing – Hazardous chemicals transportation truck, sanitation truck(sprinkler truck,water tanker truck), tow truck, high-altitude operation truck and emergency relief truck.

Our company has passed the authentication below:

-Product quality: GB/T19001-2016(ISO 9001:2015)

-Environment protection: GB/T45001-2020/ISO45001-2018

-Worker health and safety protection: GB/T28001-2011/OHSAS18001:2007

-After-sale service: GB/T27922-2011(Chinese National Standard)

-AAA Enterprise Credit Rating Certification (Hubei province)

-CCC Certification (CCC is abbreviation of China Compulsory Certificate).

And the product qualification ratio of our company reaches 99.5%.

Moreover, our products have been exported to over 20 countries such as Philippine,Cambodia,Tanzania,Costa Rica,Bolivia,Chile,Republic of Columbia,Ethiopia,Venezuela, etc..

Our company holds the faith that “quality, credit standing, technology and full-process service” is key to serving customers and aims to provide high-quality special automobile to clients all over the world.
