Prefabricated Steel Structure Warehouse Q235B Q355B 50 Years Life
Prefabricated Steel Structure Warehouse Q235B Q355B 50 Years Life
Prefabricated Steel Structure Warehouse Q235B Q355B 50 Years Life
Prefabricated Steel Structure Warehouse Q235B Q355B 50 Years Life
Prefabricated Steel Structure Warehouse Q235B Q355B 50 Years Life
Prefabricated Steel Structure Warehouse Q235B Q355B 50 Years Life
Prefabricated Steel Structure Warehouse Q235B Q355B 50 Years Life
Prefabricated Steel Structure Warehouse Q235B Q355B 50 Years Life
Prefabricated Steel Structure Warehouse Q235B Q355B 50 Years Life
Prefabricated Steel Structure Warehouse Q235B Q355B 50 Years Life
Prefabricated Steel Structure Warehouse Q235B Q355B 50 Years Life
Prefabricated Steel Structure Warehouse Q235B Q355B 50 Years Life
Specifications
Brand Name :
Ruly Steel
Model Number :
Ruly0350
Certification :
SGS, BV
Place of Origin :
China
MOQ :
500 Square Meter
Price :
USD29-USD99 Per Square Meter
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
20000 Square Meter Per Month
Delivery Time :
30 Days
Packaging Details :
As request
Application :
Logistics Steel Structure Warehouse
Features :
Prefabricated Steel Buildings
Type :
Steel Structure Warehouse
Raw steel material :
Q235B, Q355B
Surface treatment :
Painting or Hot-dip Galvanize
Service life :
50 Years
Wall and Roof :
Glass wool
Working scope :
Design,Fabrication, Installation
Description
Prefabricated Logistics Steel Structure Warehouse Construction
Product Specifications
Application Logistics Steel Structure Warehouse
Features Prefabricated Steel Buildings
Type Steel Structure Warehouse
Raw steel material Q235B, Q355B
Surface treatment Painting or Hot-dip Galvanize
Service life 50 Years
Wall and Roof Glass wool
Working scope Design, Fabrication, Installation
Project Overview

Our prefabricated steel structure warehouse offers superior construction efficiency with factory-prefabricated components that enable rapid on-site assembly. A 6,000 square meter building can be installed in just 40 days.

Key Advantages
  • Lightweight yet strong: High strength-to-weight ratio enables large spans
  • Cost-effective: Reduced foundation requirements and faster completion times
  • Design flexibility: Multiple color options and material choices for walls
  • Durable: 50-year service life with proper maintenance
Technical Specifications
Structure Type Portal frame, single ridge, two span
Dimensions 160m (L) × 60m (W) × 12m (Eave Height)
Roof Slope 10%
Gable Wall Column Spacing 7.5m
Roof/Wall Material 75mm thick Glass wool sandwich panel
Door/Window Sliding door / Ribbon Skylight
Structural Components
Component Specification
Main Structure H section steel Q355, alkyd painting
Roof/Wall Purlin XZ160*60*20*2.5, galvanized
Fasteners Grade 10.9 intensive bolts, M20/M12 galvanized bolts
Bracing System Round steel bars and angle steel (Q235), painted
Prefabricated Steel Structure Warehouse Q235B Q355B 50 Years Life
Installation Process
  • Detailed shop drawings provided prior to installation
  • Optional on-site training at our factory
  • Sample structure assembly available for reference
Prefabricated Steel Structure Warehouse Q235B Q355B 50 Years Life
Packaging & Shipping

All components are securely packed for ocean transportation in 40'HQ containers. Our skilled workers handle loading with cranes and forklifts to prevent damage during transit.

Prefabricated Steel Structure Warehouse Q235B Q355B 50 Years Life
Why Choose Our Solution
  • Cost-efficient: Optimized design reduces material usage and construction time
  • Eco-friendly: Recyclable materials with excellent insulation properties
  • Versatile: Customizable for various industrial applications
  • Proven quality: Long-term partnerships with satisfied clients worldwide
Customization Options

We design and fabricate customized steel structures for diverse applications including warehouses, workshops, hangars, commercial buildings, and industrial facilities.

Request a Quote

Please provide the following information for an accurate quotation:

1. Location Country and area where building will be constructed
2. Dimensions Length × Width × Height (in mm)
3. Environmental Factors Wind load, snow load, and earthquake resistance requirements
4. Wall Specifications Brick wall height (if applicable) and insulation requirements
5. Accessories Door/window quantities/sizes and crane specifications
