Specifications
Brand Name :
Ruly Steel
Model Number :
Ruly0425
Certification :
SGS, BV, ISO
Place of Origin :
China
MOQ :
300 Square Meter
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
20000 Square Meter Per Month
Delivery Time :
15 ~ 20 Days
Packaging Details :
As request
Application :
Prefabricated Steel Structure Corn Granary
Features :
Large-Span Steel Structure Warehouse
Type :
Steel Structure Warehouse
Raw steel material :
Q235B, Q355B, ASTM A36
Service life :
50 Years
Wall and Roof :
Steel cladding sheet
Surface treatment :
Painting
Working scope :
Design,Fabrication, Installation
Description
Large Span Steel Structure Warehouse Prefabricated Steel Structure Corn Granary
Product Attributes
Application Prefabricated Steel Structure Corn Granary
Features Large-Span Steel Structure Warehouse
Type Steel Structure Warehouse
Raw steel material Q235B, Q355B, ASTM A36
Service life 50 Years
Wall and Roof Steel cladding sheet
Surface treatment Painting
Working scope Design, Fabrication, Installation
Product Description

This large-span steel structure warehouse/prefabricated steel structure corn granary is designed for efficient storage solutions with a durable steel frame construction. The structure features three spans, each equipped with a 5T overhead crane for material handling.

The main steel frame consists of welded H-shaped steel beams and columns, with rock wool sandwich panels for roof and wall insulation. This construction type is ideal for various industrial applications including warehouses, factories, workshops, and commercial buildings.

Large-Span Prefabricated Steel Structure Corn Granary Warehouse
Steel Structure Material Specifications
Item name Specification Material Parameter Technical Treatment
Column H shape, Box, steel pipe, Hot rolled sheet Q235B, Q345B Paint or Hot dip galvanized
Beam H shape, steel Truss, Hot rolled sheet Q235B, Q345B Paint or Hot dip galvanized
Bracing Steel rod, Steel pipe, Angle steel Q235B, Q345B
Purling C or Z shape, purling Thickness:1.8mm~3.0mm Q235B, Q346B Hot dip galvanized
Wall and roof panel EPS, Rock wool, Pu, Glass wool Sandwich panel or Single sheet Steel T=0.426~0.8mm, insulation T=50~150mm Alu-zinc 150g, Fluorocarbon paint
Large-Span Prefabricated Steel Structure Corn Granary Warehouse
Our Steel Structure Factory
Large-Span Prefabricated Steel Structure Corn Granary Warehouse
Quality Control for Steel Structure Fabrication
  • Raw material quality control: Thickness tolerance <0.25mm, yield and tension strength testing in-house
  • Structural steel fabrication: 100% testing dimension tolerance <1mm, 20% sample welding line ultrasonic testing
  • Surface treatment: Shot blasting grade Sa. 2.5, paint primer within 5 hours after shot blasting
  • Pre-assembly testing: All connection details verified before shipment
Large-Span Prefabricated Steel Structure Corn Granary Warehouse
Packing & Loading

All structural components, panels, bolts, and accessories are packed with standard ocean transportation packaging and loaded into 40'HQ containers. Our skilled workers use cranes and forklifts at our factory loading site to ensure damage-free transportation.
