VR54KM-TFP-522 Scroll Compressor 380V 50Hz For Industry Air Conditioner
VR54KM-TFP-522 Scroll Compressor 380V 50Hz For Industry Air Conditioner
VR54KM-TFP-522 Scroll Compressor 380V 50Hz For Industry Air Conditioner
VR54KM-TFP-522 Scroll Compressor 380V 50Hz For Industry Air Conditioner
Specifications
Brand Name :
Copeland
Model Number :
VR54KM
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
discussed
Payment Terms :
T/T
Supply Ability :
5,000pcs per month
Delivery Time :
7-10 working days after receiving payment
Packaging Details :
Wooden case or 12 units in one pallet
Type :
Compressor
mode :
VR54KM
Warranty :
1 Year
Voltage :
380v/50hz
Horse Power(hp) :
4.5
Currency A :
7.2
BTU/H :
46300
EER btu/wh :
11.0
Power Source :
380V
Description
VR54KM-TFP-522 Scroll Compressor 380V 50Hz For Industry Air Conditioner
Product Overview

Scroll Compressor for industry air conditioner VR54KM-TFP

Brand name compressor
Place of origin China
Model VR54KM-TFP-522
Phase 1
Voltage 380V
Frequency 50Hz
Power (HP) 4.5HP
Capacity Watt 13566
Btu/h 46300
Input power 3890
COP 3.49
EER Btu/Wh 11.9
Displacement cc/rev. 73.0
Net Weight (kg) 30.4
Key Features
  • ZR series scroll compressor can be used for air conditioning and refrigeration
  • Refrigerant: R22 Volt/HZ: 220/380V 50/60 Hz
  • Outstanding reliability
  • Fewer moving parts
  • Compliance feature offers unprecedented liquid handling capability
  • Internal motor protection from high temperature and high current
  • Very low noise/gas pulsation
  • Five decibels quieter than piston compressor
  • Simplified system design
  • Unique unload start feature requires no start capacitors/relay
  • High heat pump capacity due to nearly 100% volumetric efficiency
  • Selection scope ranges from 1HP to 30HP, and is expanding
Technical Data Specifications
Model Horsepower (HP) Refrigerating Capacity (W) Input Power (W) Electricity (A) Displacement (cc/Rev.) Oil Capacity (L) Net Weight (KG) Locked-Rotor Current (A) Noise Power
VR30KM2.5740022104.540.50.7719.635.063.0
VR32KS2.7790024104.344.30.7422.134.068.0
VR34KF2.8830025604.546.20.7422.134.068.0
VR48KS4.01186728006.165.61.3630.050.068.0
VR50KS4.21230036206.767.41.3630.059.068.0
VR52KS4.31280037707.070.41.4830.059.069.0
VR52KM4.31306837507.170.41.4830.458.069.0
VR54KS4.51320039207.473.11.4830.058.069.0
VR54KM4.51356638907.273.01.4830.458.069.0
VR57KF4.81390043209.177.21.3630.058.769.0
VR57KS4.81390041307.877.21.3628.658.069.0
VR61KF5.11490044708.382.71.3630.058.069.0
VR84KS7.020800600011.9113.62.5157.290.073.0
VR94KS7.823300675012.5127.22.5157.286.073.0
VR108KS9.026400755013.7142.93.2559.9100.074.0
VR125KS10.431000900015.8167.23.2561.2110.075.0
VR125KF10.431100914016.7167.23.2561.2153.075.0
VR144KS12.0350001010017.6190.93.2561.2110.076.0
VR144KF12.0352001025018.5190.93.2561.2153.076.0
VR160KS13.3382001130020.2209.33.2564.9133.079.0
VR190KS15.8456001360025.6249.33.2566.2168.082.0
