GKM398 MEMS Analog Vibration Sensor Current Type With 4 M4 Screws
GKM398 MEMS Analog Vibration Sensor Current Type With 4 M4 Screws
GKM398 MEMS Analog Vibration Sensor Current Type With 4 M4 Screws
GKM398 MEMS Analog Vibration Sensor Current Type With 4 M4 Screws
GKM398 MEMS Analog Vibration Sensor Current Type With 4 M4 Screws
GKM398 MEMS Analog Vibration Sensor Current Type With 4 M4 Screws
Specifications
Model Number :
GKM398
Measurement Range :
±2g / ±4g / ±8g / ±10g / ±20g / ±40g
MOQ :
1
Brand Name :
RUICOM
Installation Method :
Standard / Magnetic Adhesive Base
Supply Ability :
100000 pieces/year
Payment Terms :
T/T
Delivery Time :
7-15days
Certification :
CE, RoHS
Place of Origin :
Shenzhen, China
Description

The GKM398 triaxial Vibration sensor is an independently developed by RUICOM Technology, applicable to vibration testing, impact testing, and other fields. This product employs an analog current output design, supports address code settings, and allows multiple sensors to be used in series over long distances, facilitating multi-point measurement and data analysis.


The GKM398 utilizes single-crystal silicon capacitive sensing technology. Its core components include a micromachined silicon chip, a low-power ASIC signal conditioning circuit, a microprocessor for storing compensation data, and an integrated temperature sensor. The product undergoes precise calibration and features low power consumption, stable structure, and reliable output. Its electronic system employs a solid-state power supply reset design and provides overcurrent protection to ensure safe operation.


This series of products, with its robust structural design, excellent power consumption control, and good deviation stability, meets the requirements for high-reliability measurements.


Technical Characteristics

❖ Analog current output interface;

❖ Vibration: 10~2000Hz, 10g;

❖ Shock: 100g@11ms, triaxial (half-sine wave);

❖ Excellent mechanical strength and long-term stability.


Application Field

❖ Flight data recording and analysis ❖ Structural fatigue monitoring and life prediction

❖ Bridge structural health monitoring ❖ Track vibration and roadbed stability monitoring

❖ Vehicle vibration testing and monitoring ❖ High-speed train operation status monitoring

❖ Wind turbine generator vibration monitoring ❖ Vibration fault early warning for large machinery

❖ Monitoring of heavy equipment such as road rollers

GKM398 MEMS Analog Vibration Sensor Current Type With 4 M4 Screws


Performance Parameters

GKM398

Parameter

Unit

Measurement Range

±2

±4

±8

±10

±20

±40

g

Bias Calibration

<1

<1

<1

<1

<1

<1

mg

Measurement Axis

X,Y,Z

X,Y,Z

X,Y,Z

X,Y,Z

X,Y,Z

X,Y,Z

axis

Upward/Power-Off Repeatability

<2

<2

<2

<2

<2

<2

mg(max)

Sensitivity (±10%)

4

2

1

0.8

0.4

0.2

mA/g

Bias Temperature Coefficient

0.01

0.01

0.01

0.05

0.05

0.05

%/℃

Resolution/Threshold (@ 1Hz)

< 1

< 1

< 1

< 1

< 1

< 1

mg(max)

Nonlinearity

<1

<1

<1

<1

<1

<1

% FS(max)

Response Frequency

500

500

500

500

500

500

Hz

Bandwidth (3dB)

1000

1000

1000

1000

1000

1000

Hz

Cross-Axis Sensitivity

1

1

1

2

2

2

%

Transverse Vibration Sensitivity Ratio

1

1

2

5

5

5

%

Resonant Frequency

2.4

2.4

2.4

5.5

5.5

5.5

kHz

Noise Density

21

21

21

86.6

86.6

86.6

μg/√Hz

0g Output 12mA

<0.005

<0.005

<0.005

<0.003

<0.003

<0.003

mA

Output Current

4~20mA

Input (VDD_VSS)

9-36 VDC

Operating Current Consumption

<60mA @ 12 VDC

Protection Class

IP67

Material

Aluminum Alloy

Weight

Net Weight: ≤116g / Magnetic Base: ≤50g

Product Dimensions

Product Dimensions: L36×W32×H24mm
Magnetic Base Dimensions: L36×W32×H8.1mm

Note: Do not use beyond the specified range for extended periods.


PIN Definition

PIN/Thread Color

Definition

PIN1/Brown

DC9 ~36V

PIN2/White

X-axis current signal

PIN3/Blue

Y-axis current signal

PIN4/Black

GND

PIN 5/Yellow-green

Z-axis current signal


GKM398 MEMS Analog Vibration Sensor Current Type With 4 M4 Screws


Product Dimensions

Housing: L36×W32×H24mm

Installation Dimensions: L29×W25×H4mm

Mounting screws: 4 M4 screws

GKM398 MEMS Analog Vibration Sensor Current Type With 4 M4 Screws



Installation Accessory Dimensions

Magnetic base plate dimensions: L36×W32×H8.1mm

Installation Dimensions: L29×W25×H11.6mm

Installation method: Magnetic adsorption base installation
