Specifications
Brand Name :
ZL
Model Number :
ZL-1509
Certification :
CE,ISO
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
40 sets / month
Delivery Time :
4-7 work days
Packaging Details :
Sensing Projector Impact Specimen U/V Notch Profile Projector Measuring Specimen Projector Vertical Projector is packaged within wooden case.
Product name :
Sensing Projector Impact Specimen U/V Notch Profile Projector Measuring Specimen Projector Vertical Projector
Projection screen size (mm) :
Φ312
usable range :
greater than Φ300
Projection screen rotation range :
0-360º
Rotation angle digital display resolution :
1′ or 0.01º, utilising Japanese rotary encoder
Cooling Method :
Forced air cooling (3 axial fans)
Instrument Power Supply :
110V/220V (AC) 50/60Hz, total power 400W
Instrument Dimensions :
Length * Width * Height (mm): 788 * 524 * 1152
Description
Sensing Projector Impact Specimen U/V Notch Profile Projector
Professional vertical projector system designed for precise measurement of impact specimens with U/V notch profiles, featuring advanced optical projection and digital measurement capabilities.
Instrument Accessories
Projection Screen
  • Projection screen size: Φ312mm with usable range greater than Φ300mm
  • Japanese lithography technology with engraved grid lines
  • Rotation range: 0-360°
  • Digital display resolution: 1′ or 0.01° using Japanese rotary encoder
Objective Lens Specifications
Ratio 10X 20X (Option) 50X (Option) 100X (Option)
Field of View (mm) Φ30 Φ15 Φ6 Φ3
Working Distance (mm) 77.7 44.3 38.4 25.3
Max. Measurement Height (mm) 90 90 90 90
Distance Measurement System
DP-300C multifunction digital display meter with Japanese materials and full Chinese-language display. Capable of multi-point sampling, coordinate rotation, and measurements of points, lines, circles, distances, and angles.
Instrument Lighting
Transmitted and reflected lighting using imported German Osram 24V, 150W halogen lamps.
Cooling System
Forced air cooling with 3 axial fans for optimal temperature control.
Power Supply
110V/220V (AC) 50/60Hz, total power consumption: 400W
Instrument Dimensions
Length * Width * Height: 788 * 524 * 1152 mm
X, Y Workbench
Constructed from ductile iron casting with precision machining and special stabilization treatment to ensure superior measurement accuracy and stability.
Transmission Method
Japanese toothless optical rod transmission for smooth and precise operation.
