Specifications
Brand Name :
ZL
Place of Origin :
Guangdong, China
MOQ :
1
Max load :
5KN,1ton,2 ton
Effective measuring range :
0.2%~100%(1grade)/0.4%~100%(0.5 grade)
Measuring accuracy :
Display the value ±1%/Display the value±0.5%
Tester resolution :
Max load 1/200000
Effective testing width :
390mm
Effective Tensile stroke :
800mm;1000mm;1200mm
Range of testing speed :
0.001~200mm/min ; 500mm/min
Accuracy of displacement measurement :
Tolerance: ±0.5%/ tolerance: ±0.2%
Deformation measured system :
Min span:10mm, Max range:800mm
Accuracy of measured deformation :
Tolerance: ±0.5%
Overload protection :
Overload 10%,automatic protection
Machine size :
80x55x220cm
Power supply :
220V,50HZ
Power :
0.4KW
Machine weight :
250kg
Description
20KN Universal Testing Machine | Mechanical Tensile Tester
Product Overview

The High Temperature Universal Tensile Strength Testing Machine combines electronic technology with mechanical transmission for precise material testing. It features accurate load speed, force measurement range, and high sensitivity for load and displacement measurement and control.

Key Features
  • Tests constant-velocity loading and displacement
  • Simple operation ideal for production line quality control
  • Equipped with large deformation extensometer for flexible materials
  • Photoelectric encoder for displacement measurement
  • Automated calculations for stress, elongation rate, tensile strength, and elastic modulus
  • Computer display of dynamic test curves and data processing
Applications

Ideal for testing flexible materials with large deformation including rubber, plastics, leather, and more. Performs tensile, tear, adhesive strength, and peel tests.

Technical Specifications
Parameter Specification
Max Load 5KN, 1ton, 2 ton
Accuracy Grade 1% / 0.5%
Effective Measuring Range 0.2%~100%(1grade)/0.4%~100%(0.5 grade)
Testing Speed Range 0.001~200mm/min; 500mm/min (1000mm/min optional)
Effective Testing Width 390mm (customizable)
Power Supply 220V, 50HZ, 0.4KW
Machine Weight 250kg
20KN Universal Testing Machine | Mechanical Tensile Tester | Competitive Price for Material Testing 20KN Universal Testing Machine | Mechanical Tensile Tester | Competitive Price for Material Testing 20KN Universal Testing Machine | Mechanical Tensile Tester | Competitive Price for Material Testing
Industries Served

Rubber & Plastics, Metallurgy, Manufacturing, Electronics, Automotive, Textiles, Packaging, Food, Medical Equipment, Research Laboratories, and more.

Frequently Asked Questions
How to choose the most suitable Mechanical Equipment?

Our professional team will provide recommendations based on your specific testing requirements and specifications.

What's the delivery term?

Typically 15-20 working days after deposit receipt. Urgent orders can be accommodated with special arrangements.

Do you accept customization service?

Yes, we offer both standard and customized machines tailored to your specific requirements.

What is your warranty policy?

We offer a two-year warranty with technical support and parts replacement as needed.
