Specifications
Effective measuring range :
0.2%~100%(1grade)/0.4%~100%(0.5 grade)
Effective Tensile stroke :
800mm; 1000mm; 1200mm
Machine weight :
250kg
Effective testing width :
390 mm
Maximum load :
5KN, 1ton, 2 ton
Power :
0.4KW
Displacement accuracy :
±0.5%
Power supply :
220V 50HZ
Deformation accuracy :
±0.5%
Model Number :
ZL-8001C
Brand Name :
ZL
Place of Origin :
Guangdong, China
MOQ :
1
Measuring accuracy :
Display the value ±1%/Display the value±0.5%
Testing speed range :
0.001~200mm/min; 500mm/min
Machine size :
80*55*220 cm
Tester resolution :
Max load 1/200000
Accuracy grade :
1% /0.5%
Overload protection :
Overload 10%, automatic protection
Description
\n
\n
High Temperature Micro Tensile Tester | ISO 783 Compliance | for High Pressure & Elevated Temperature Testing
\n
\nHigh Pressure and Temperature Micro Tensile Testing Machine\n
\n
Equipment Summary
\n
\n The Electronic High Temperature Universal Tensile Testing Machine combines electronic technology with mechanical transmission for precise material testing. It features accurate load speed, wide force measurement range, and high sensitivity for load and displacement measurement. Capable of constant-velocity loading and displacement testing, this machine is ideal for quality control in production lines, particularly for non-metallic and metallic materials with loads under 1 ton.\n
\n
Main Functions
\n
\n This testing machine is designed for flexible materials with large deformation, such as rubber, plastics, and leather. It performs tensile, tear, adhesive strength, and peel tests, equipped with a large deformation extensometer for specialized material measurements.\n
\n
Applicable Industries
\n
\n
    \n
  • Quality control
    • \n
  • Rubber & Plastics
    • \n
  • Metallurgical iron and steel
    • \n
  • Manufacturing machinery
    • \n
  • Electronic equipment
    • \n
  • Automobile production
    • \n
  • Textile fiber
    • \n
  • Wire and cable
    • \n
  • Packaging materials and foodstuffs
    • \n
  • Medical equipment
    • \n
  • Civil aviation
    • \n
  • Research laboratories
    • \n
  • Technical supervision departments
    • \n
  • Petroleum & Chemical industries
    • \n
\n
\n
Technical Parameters
\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n
ParameterSpecification
ModelElectronic High Temperature Universal Tensile Testing Machine
Max load5KN, 1ton, 2 ton
Accurate grade1% / 0.5%
Effective measuring range0.2%~100%(1grade)/0.4%~100%(0.5 grade)
Measuring accuracyDisplay value \u00b11%/Display value\u00b10.5%
Tester resolutionMax load 1/200000, constant resolution
Load sensorBasic configuration: one sensor; Extended configuration available
Effective testing width390mm (customizable)
Effective Tensile stroke800mm; 1000mm; 1200mm (customizable)
Range of testing speed0.001~200mm/min; 500mm/min (1000mm/min optional)
Accuracy of displacement measurement\u00b10.5%/\u00b10.2%
Power systemhigh-performance AC Servo Motor + Driver + high-precision ball screw
Power supply220V, 50HZ
Machine weight250kg
\nHigh Temperature Micro Tensile Tester | ISO 783 Compliance | for High Pressure & Elevated Temperature Testing\nHigh Temperature Micro Tensile Tester | ISO 783 Compliance | for High Pressure & Elevated Temperature Testing\n
Main Features
\n
\n
    \n
  • Photoelectric encoder for displacement measurement
    • \n
  • Embedded microcontroller with multifunction software
    • \n
  • Automatic calculation of stress, elongation rate, tensile strength, and elastic modulus
    • \n
  • Computer display of dynamic testing curves
    • \n
  • Data reanalysis and curve amplification capabilities
    • \n
  • International advanced performance level
    • \n
\n
\n
About Us
\n
\n Zhongli Instrument Technology Co., Ltd is an instrument expert headquartered in Dongguan, Guangdong, China. Since 2007, we have specialized in manufacturing lab testing equipment. Our products are sold in over 113 countries, particularly favored in European and American markets. We serve industries including rubber and plastics, food, packaging, and electronics, providing equipment for research units, quality inspection institutions, and academic fields. Our R&D team offers customization services to meet specific requirements.\n
\nHigh Temperature Micro Tensile Tester | ISO 783 Compliance | for High Pressure & Elevated Temperature Testing\n
FAQ
\n
\n
How to choose the most suitable Mechanical Equipment?
\n
Our professional team will provide recommendations based on your testing requirements and specifications.
\n
\n
\n
What's the delivery term?
\n
Typically 15-20 working days after deposit receipt. Urgent orders can be specially arranged.
\n
\n
\n
Do you accept customization service?
\n
Yes, we offer both standard and customized machines to meet specific requirements.
\n
\n
\n
Can we visit your factory before order?
\n
We welcome factory visits and can assist with hotel arrangements and airport pickup.
\n
\n
\n
How about your warranty?
\n
Two-year warranty with technical support and potential on-site engineer service.
\n
\n
\nWelcome to visit our Official Website: www.zltester.com\n
