Specifications
Model Number :
ZL-3080-10
Brand Name :
ZL
Payment Terms :
Western Union,T/T,D/P,D/A,L/C
Resolution :
Better than 1.0 cm⁻¹
Data Interface :
USB 2.0 (Compatible with USB 3.0)
Supply Ability :
50
Wavenumber Range :
7800 ~ 375 cm⁻¹
Place of Origin :
China
Name :
FTIR Spectrometer
MOQ :
1
Delivery Time :
14 work days
Signal-to-Noise Ratio (SNR) :
Better than 15,000:1 / 30,000:1 (Peak-to-Peak, 4 cm⁻¹, 1-minute scan) – Optional
Certification :
CE
Price :
UDS26000
Wavenumber Accuracy :
≤ 0.01 cm⁻¹
Description
ASTM E168 ISO10640 FTIR Spectrometer Fourier Transform Infrared Spectrometer for Polymer Rubber Plastic Material
The ZL-3080 Fourier Transform Infrared Spectrometer is a product meticulously and independently developed by Dongguan Zhongli Instrument Technology Co., Ltd. Featuring convenient installation, simple operation, and easy maintenance, it has become an indispensable spectroscopic analysis instrument in fields such as materials science, biomedicine, petrochemicals, and food safety. It is also an essential laboratory instrument for related majors in universities and research institutes.
Operating Principle
The FTIR utilizes the Michelson interferometer principle. Light emitted by the source passes through the Michelson interferometer to create optical interference, which then illuminates the sample. The receiver captures the interference light containing sample information, and computer software performs Fourier transformation to obtain the sample spectra.
Product Features
  • Advanced technology with mature, well-integrated design
  • Incorporates advanced foreign technology and cutting-edge design concepts
  • Performance and key technical specifications meet international standards
  • Convenient installation, simple operation, and easy maintenance
Technical Specifications
Specification Value
Wavenumber Range 7800 ~ 375 cm⁻¹
Resolution Better than 1.0 cm⁻¹
Wavenumber Accuracy ≤ 0.01 cm⁻¹
Signal-to-Noise Ratio (SNR) Better than 15,000:1 / 30,000:1 (Peak-to-Peak, 4 cm⁻¹, 1-minute scan) - Optional
Beamsplitter Germanium-coated KBr substrate (Imported)
Light Source High-energy, high-efficiency, long-life ceramic light source (Imported)
Interferometer Michelson interferometer with 30° incident angle
Detector High-sensitivity DLATGS detector with moisture-proof coating (Imported)
Data Interface USB 2.0 (Compatible with USB 3.0)
Dimensions 450mm (W) × 350mm (D) × 210mm (H)
Weight 14Kg
