Electronic Rubber Tensile Testing Machine , 5KN Fabric Textile Testing Machine
Electronic Rubber Tensile Testing Machine , 5KN Fabric Textile Testing Machine
Electronic Rubber Tensile Testing Machine , 5KN Fabric Textile Testing Machine
Electronic Rubber Tensile Testing Machine , 5KN Fabric Textile Testing Machine
Electronic Rubber Tensile Testing Machine , 5KN Fabric Textile Testing Machine
Electronic Rubber Tensile Testing Machine , 5KN Fabric Textile Testing Machine
Electronic Rubber Tensile Testing Machine , 5KN Fabric Textile Testing Machine
Electronic Rubber Tensile Testing Machine , 5KN Fabric Textile Testing Machine
Specifications
Brand Name :
Zhongli
Model Number :
ZL-8003C
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T,L/C,D/A,D/P,Western Union,MoneyGram
Supply Ability :
100 sets per month
Delivery Time :
10 days after order
Packaging Details :
Strong Wooden Case
Power: :
Electronic
Usage: :
Textile Testing Instrument
Max load: :
1KN , 2KN, 5KN
Tester resolution: :
1/50000
Max. test stoke: :
About 500mm
Measuring accuracy :
± 0.5%
Data sampling frequency: :
200times/sec
Power supply: :
220V,50HZ
Description
5KN Fabric / Rubber Universal Tensile Strength Testing Machine
This electronic universal testing machine performs tensile, compression, bending, shear, peel, tear, and two-point extension tests for quality control across various materials including textiles, rubber, plastics, synthetic leather, tape, adhesives, plastic film, composites, electronics, and metals.
Key Features
  • Premium aluminum construction with electrostatic spray finish
  • Digital force display with clear LCD readout for tension and pressure
  • Multiple unit options: N, Kg, Lb, Ton with automatic conversion
  • Backlit LCD for low-light environment operation
  • Single measurement with automatic recording of maximum tension and compression forces
  • Overload and over-trip automatic shutdown protection
  • Elegant single-column design for comfortable seated operation
Technical Specifications
Model 5KN Fabric / Rubber Universal Tensile Strength Testing Machine
Maximum Load 5KN high-precision sensors from U.S.A.
Capacity Options 1KN, 2KN, 5KN
Units KG, N, LB, TON
Measurement System Load cell + HZ-2000
Measurement Accuracy ± 0.5% (full range of 5% - 100%)
Resolution 1 / 50000
Maximum Test Stroke Approximately 500mm (customizable)
Test Speed 50-300mm/min with stepless speed and 5 fixed speeds (customizable)
Data Sampling Frequency 200 times/sec
Display ZL-2000 dark blue LCD with membrane touch keys
Machine Dimensions 45*58*135cm (L*W*H)
Weight 75KG
Power System AC Motor, 120W
Power Supply 1Φ, 220V, 15A
Advanced Functions
  • Single test with 10-point statistics and automatic average calculation
  • Multi-unit automatic exchange (kg, Lb, N)
  • Free point selection capability
  • Multi-calibration functionality
  • Automatic printing of test results
  • 24-bit AD acquisition with 1/200,000 resolution
  • Breakpoint ratio from 0-99% for material-specific stopping
  • Overload protection with configurable settings
  • Password protection for operational security
Compliance Standard
GB/T16491-1996 electronic universal testing machine
