ISO-5470 Rubber / Leather Testing Machine For Taber Abrasion Test
ISO-5470 Rubber / Leather Testing Machine For Taber Abrasion Test
ISO-5470 Rubber / Leather Testing Machine For Taber Abrasion Test
ISO-5470 Rubber / Leather Testing Machine For Taber Abrasion Test
ISO-5470 Rubber / Leather Testing Machine For Taber Abrasion Test
ISO-5470 Rubber / Leather Testing Machine For Taber Abrasion Test
ISO-5470 Rubber / Leather Testing Machine For Taber Abrasion Test
ISO-5470 Rubber / Leather Testing Machine For Taber Abrasion Test
Specifications
Brand Name :
ZL
Model Number :
ZL-7031
Certification :
ISO , CE
Place of Origin :
China
MOQ :
1 SET
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
100 SET PER MONTH
Delivery Time :
3-7 Days
Packaging Details :
ISO-5470 Rubber / Leather Testing Machine For Taber Abrasion Test is Packaged within safety wooden case (fumigation free）
Product name :
ISO-5470 Rubber / Leather Testing Machine For Taber Abrasion Test
Power :
AC220V / 50HZ
Specimen :
120 * 6.5 * 3mm
Load :
250g, 500g, 1000g
Machine dimension :
30 * 43 * 30cm
Weight :
35kg
Testing Disk Speed :
0-70 Adjustable
Key words :
Taber Abrasion
Description
ISO-5470 Rubber / Leather Testing Machine For Taber Abrasion Test
Product Overview

The ISO-5470 Rubber/Leather Testing Machine is designed for Taber Abrasion testing, providing reliable performance evaluation for various materials through standardized wear resistance testing.

Applicable Industries

This Rubber Taber Abrasion Tester is used in testing the performance of numerous materials including:

  • Leather products, suitcases, and carpets
  • Cardboard, clothing, and textiles
  • Glass, plastic coatings, and ceramic tiles
  • Metal plating, paints, and varnishes
  • Decorative sheets, high-pressure sheets, and plastics
  • Flexible floor mats and traffic paint
  • Anodizing layers, blankets, and electronic components
  • Decorative plates, wax, labels, and dental materials
  • Car ornaments, resin, furniture, and scientific research labs
  • Commodity inspection, arbitration, and technical supervision departments
Compliance Standards

The DIN 53754 Leather Rubber Taber Abrasion Tester meets the following international standards:

  • DIN-53754, 53799, 53109, 52347
  • TAPPI-T476
  • ASTM-D1044, D3884
  • ISO-5470
Technical Specifications
Parameter Specification
Model DIN53754 Leather Rubber Taber Abrasion Tester
Specimen 120 × 6.5 × 3mm
Load 250g, 500g, 1000g
Counter 6 digit electronic display, automatic shut down
Testing Disk Speed 0-70 Adjustable
Machine Dimensions 30 × 43 × 30cm
Machine Weight 30kg
Power AC220V / 50HZ

Included Attachments: One wrench, one set of grinding wheels, Fama weights (250g, 500g, 750g) - 2 pieces each, and one vacuum cleaner.

Testing Methodology

The Rubber Taber Abrasion Tester evaluates wear resistance in materials such as skin, leather, cloth, paint, paper, flooring, plywood, glass, and natural rubber. The testing procedure involves:

  • Using a standard knife to cut the specimen
  • Applying regulated models of grinding wheels with specified loading weights
  • Abrasing the specimen through rotation for a predetermined number of cycles
  • Observing the specimen condition or comparing weight with original materials

Available Grinding Wheel Models: H18, H22, CS17, S32, S33

Testing Reference Guide
Material Type Recommended Grinding Wheel
Paint CS10, CS17
Brick CS17
Plywood S32, S33
Plastic CS17, H18, H22
Product Images
ISO-5470 Rubber / Leather Testing Machine For Taber Abrasion Test ISO-5470 Rubber / Leather Testing Machine For Taber Abrasion Test ISO-5470 Rubber / Leather Testing Machine For Taber Abrasion Test
