DX8373 Door Roller Shutter Fire Resistance Testing Machine (Door And Roller Shutter Fire Resistance Testing Furnace)
DX8373 Door Roller Shutter Fire Resistance Testing Machine (Door And Roller Shutter Fire Resistance Testing Furnace)
Specifications
Brand Name :
DAXIAN
Model Number :
DX8373
Certification :
ISO3008 GB/T7633
Place of Origin :
China
MOQ :
One set
Price :
US$2000-$30000
Payment Terms :
L/C, T/T
Delivery Time :
5-8 work days
Packaging Details :
Wooden cases
Working power supply: :
AC 380V ±10%, 50Hz; power consumption: 3kW
Furnace pressure measurement range: :
0–100Pa, measurement accuracy: ≤ ±3Pa
Air flow range: 0–50m³/min, measurement accuracy: :
≤ ±0.5m³/min
 Combustion gas source: :
propane, liquefied petroleum gas
Gas flow range: :
0–100L/min, measurement accuracy: Class 2.5
Gas cylinder capacity: :
50kg × 6 cylinders
Description

DX8373 Door Roller Shutter Fire Resistance Testing Machine (door and Roller Shutter Fire Resistance Testing Furnace)

DX8373 Door Roller Shutter Fire Resistance Testing Machine (Door And Roller Shutter Fire Resistance Testing Furnace)


1. Scope of Application

Suitable for fire resistance performance tests of building doors (including single and double-leaf doors) and rolling shutters, to determine their fire resistance rating through testing.

2. Compliance Standards

Complies with GB/T 7633 Fire Resistance Test Methods for Doors and Shutters and ISO 3008 Fire Resistance Tests for Full-Size Doors and Shutters.

3. Technical Specifications

1. Working power supply: AC 380V ±10%, 50Hz; power consumption: 3kW
2. Furnace pressure measurement range: 0–100Pa, measurement accuracy: ≤ ±3Pa
3. Air flow range: 0–50m³/min, measurement accuracy: ≤ ±0.5m³/min
4. Combustion gas source: propane, liquefied petroleum gas
5. Gas flow range: 0–100L/min, measurement accuracy: Class 2.5
6. Gas cylinder capacity: 50kg × 6 cylinders
7. Specimen back surface radiant heat flux measurement range: 0–10W/cm²
8. Furnace pressure measurement range: indoor pressure ±150mPa
9. Test temperature curve: programmed heating, 15min from ambient to 718℃; 30min from ambient to 821℃; 60min from ambient to 925℃; 90min from ambient to 986℃; 120min from ambient to 1029℃

- All terms follow international fire testing equipment conventions (e.g., "fire resistance rating", "programmed heating profile").

- Units (Pa, m³/min, L/min, W/cm², °C) are standardized for technical documentation.

- The test temperature sequence is kept in the original format to align with the GB/T and ISO standard requirements.
