GW603 Compact Design Glow Wire Tester IEC 60695-2-11 Flammability Testing Equipment
GW603 Compact Design Glow Wire Tester IEC 60695-2-11 Flammability Testing Equipment
Specifications
Brand Name :
YUYANG
Power Supply :
220V 50Hz Single Phase
Model Number :
GW603
Price :
USD 800-3500 / Set
Temperature Range :
Ambient to 1000°C
Certification :
ISO 9001:2015, CE
MOQ :
1 Set
Test Force :
1.0N ± 0.2N
Place of Origin :
Guangdong, China
Control Mode :
PLC with Touch Screen
Payment Terms :
T/T, L/C, Western Union, PayPal
Packaging Details :
Export-grade plywood case with custom foam cushioning, moisture-proof barrier, and reinforced corner protection
Supply Ability :
200 Sets per Month
Delivery Time :
3-7 working days for stock models, 15-25 days for production
Test Standard :
IEC 60695-2-11
Heating Element :
Ni80/Cr20 Alloy Wire
Heating Rate :
0-1000°C within 1 minute
Penetration Depth :
7mm ± 0.5mm
Description

GW603 Glow Wire Tester - Laboratory Flammability Testing Solution

This Glow Wire Tester is designed for fire hazard testing of electrical and electronic products, household appliances, and insulating materials. Fully compliant with IEC 60695-2-11, it simulates thermal stress caused by glowing elements or overloaded resistors. The equipment uses a precisely controlled Ni80/Cr20 alloy heating wire that reaches up to 1000°C within one minute, applying a calibrated force of 1.0N to the test specimen. Ideal for glow wire ignition temperature (GWIT) and glow wire flammability index (GWFI) testing applications in quality control laboratories and third-party testing facilities. Featuring an innovative compact benchtop design that occupies minimal laboratory floor space without compromising test performance. The space-saving form factor makes this instrument ideal for testing laboratories with limited footprint, mobile testing units, and educational institutions. Despite its compact dimensions, the equipment delivers full-standard-compliant testing capability with all essential functions intact. Lightweight construction with integrated handle points enables easy relocation between workstations.

Key Features

  • Standard Compliance: Fully conforms to IEC 60695-2-11, UL 746A, GB/T 5169.10
  • Test Method: Automated test sequence with programmable parameters for reproducible results
  • Control System: Advanced PLC controller with intuitive touch screen HMI interface
  • Construction: Premium stainless steel and industrial-grade components for long service life
  • Data Output: Real-time data display with USB export and test report generation capability
  • Safety: Comprehensive protection features for laboratory operator safety
  • Warranty: 12-month manufacturer warranty with lifetime technical support

Technical Specifications

Model NumberGW603
Test StandardIEC 60695-2-11
Power Supply220V 50Hz Single Phase
Control SystemPLC with color touch screen
Construction MaterialStainless steel 304, industrial-grade
Warranty12 months
CertificationCE, ISO 9001:2015
Place of OriginGuangdong, China

Applications

Suitable for quality control laboratories, third-party testing agencies, university research departments, electronic component manufacturers, material suppliers, and regulatory compliance testing facilities worldwide.

Packaging & Delivery

  • Export-grade plywood case with foam cushioning and moisture-proof barrier
  • Complete with user manual, calibration certificate, power cable, and spare parts kit
  • Shipping via air freight (3-7 days) or sea freight (15-25 days) to global destinations
