Liquid Painting Silicon PU Coating Rubber Sports Court Flooring
Liquid Painting Silicon PU Coating Rubber Sports Court Flooring
Liquid Painting Silicon PU Coating Rubber Sports Court Flooring
Liquid Painting Silicon PU Coating Rubber Sports Court Flooring
Liquid Painting Silicon PU Coating Rubber Sports Court Flooring
Liquid Painting Silicon PU Coating Rubber Sports Court Flooring
Specifications
Brand Name :
CN Sports
Model Number :
CN-006
Certification :
IAAF / ITF/RoHS/iSSS/ISO140019001/ISO14001
Place of Origin :
China
MOQ :
/
Price :
US $9-29/ Square Meter
Payment Terms :
L/C, T/T
Supply Ability :
200000 M2/ Year
Delivery Time :
Within 15 work days after your deposit
Packaging Details :
Pack in Pallet/Bundles
Color: :
Red, green, blue, yeloow, orange, purple, etc
Material: :
Silicon PU
Shock absorption rate: :
21%
The springback value: :
30%
Tensile elongation: :
1112%
Compression recovery rate: :
97%
Package: :
by barrel, on Pallet
Flame retardant level: :
I
Thickness: :
3mm,4mm,5mm,6mm,7mm,8mm,etc
Application: :
Sports and Playground flooring surface
Description

Liquid Painting Silicon PU Coating Rubber Sports Court Flooring

Production Description

The purpose of building sports courts is to ensure a professional, safe, healthy sports condition-the characteristics of hardness will bring the professional sporting feeling; the cushion effectively increasing the shock absorption and reduce the incidence of injuries to ankles, joints and ligaments. At the same time, it should reduce abrasion caused by falling and accident.

It’s suitable to lay on concrete or asphalt substrates. The cushion elastic bottom layer plus with high performance top layer is both in good function and also cost saving.

Standard of Sports Performance

Item test project technical requirements test results
1 Shock absorption rate (%) Fr≥12 21
2 The springback value(%) ≥20 30
3 Sliding friction coefficient 0.4≤u≤0.7 0.53
4 Compression recovery rate(%) ≥95 97
5 Hardness(Shore A),20℃ 60-80 68

Durable Performance Standard

Based on the owner or operator, construction and maintenance

Reflect the quality level of the site, and durable time limit

Technical data for SPU Sports Flooring

Item test project technical requirements test results
1 Tensile elongation,% ≥400 1112
2 The tensile strength,Mpa ≥1.8 3.5
3 Artificial climate ageing resistance (300h) No bubbles, no peeling, no crack； pulverization≤grade 1,△E≤6.0 No bubbles, no peeling, no crack；pulverization＝grade 0,△E＝0.57
4 Wear resistance(750g/500r),g ≤0.050 0.031
5 Durability, aging experiment (168h) Tensile elongation,% ≥300 853
The tensile strength,Mpa ≥1.3 1.6
6

Resistance to water(168h)

 No bubbles, no peeling, allowing a slight color change,recovery after 2h No bubbles, no peeling, no discoloration
7 Flame retardant level I I

Environmental Performance Standard

Based on considerations of social environmental security responsibility

Perform interior decoration decorate material national mandatory standard, do real non-toxic harmless green material.

Standard Testing Result of SPU

Item test project technical requirements test results
1 Volatile organic compounds(VOC)(g/L) ≤670 91
2 benzene(%) ≤0.3 Did not check out
3 Toluene ＋xylene＋ ethyl benzene(%) ≤30 5
4 The free diisocyanate(TDI＋HDI)(%) ≤0.4 Did not check out
5 Halogenated hydrocarbon(%) ≤0.1 Did not check out
6

Soluble heavy metals(mg/kg)

 plumbum Pb ≤90 Did not check out
Cadmium Cd ≤75 Did not check out
chromium Cr ≤60 Did not check out
mercury Hg ≤60 Did not check out

Liquid Painting Silicon PU Coating Rubber Sports Court Flooring

Liquid Painting Silicon PU Coating Rubber Sports Court Flooring

Liquid Painting Silicon PU Coating Rubber Sports Court Flooring
