100% Italy TPM Seals And KDSAS Piston Cylinder Combination Oil Seals

1.... Operating conditions

Pressure / Speed : 50(MPa) /0.5m/s

Temperature: NBR -30℃~+110℃

Nature: Wear resistance, high pressure resistance

Speed: Maximum reciproing speed

Media: Combined seal for high pressure hydraulic pressure for shaft

Flame retardant hydraulic fluids

2..... Product name: 100% Italy TPM Seals And KDSAS Piston Cylinder Combination Oil Seals

1) Product Overview
This product is a 100% original, off-the-shelf hydraulic piston rod seal, model number TPM 100*85*20/393334, including 5 pieces of hydraulic seals. It is suitable for various hydraulic equipment and can effectively prevent the leakage of hydraulic oil and ensure the normal operation of the equipment.

2) Product features

100% original in stock, quality guaranteed, no need to worry about product quality issues.
Precise dimensional design can perfectly adapt to various hydraulic equipment.
Made of high-quality materials, wear-resistant and durable, with long service life.
Installation is simple and can be completed without the need for a professional.
3) How to use

Before replacing hydraulic seals, make sure the equipment is shut down and cool.
Remove the old hydraulic seal, being careful not to damage the new seal.
Place the new hydraulic seal into the designated location, making sure it is in full contact with the piston rod.
Use appropriate tools to hold the seal in place to avoid movement during use.
4) Precautions

Please use this product under the guidance of professionals to ensure safety.
Please check the status of hydraulic seals regularly and replace them in time if they are damaged or worn.
Please keep this product properly and avoid direct sunlight and humid environment.

3.... Material

Material: Profile seal: NBR

Back-up Ring: Polyester elastomer

Guide rings: POM

4.... Packaging & Delivery

Packaging Details : The original factory packaging

Dellvery Time :

5.... Precautions for storage

Please pay attention to the following items when storing the seal:

1) Please do not open the package when it is not needed.
Otherwise, the seal may get "dust" or be "scratched".

2) Please store in a place with low humidity and avoid direct sunlight.
Ultraviolet rays and moisture accelerate the deterioration of rubber materials and the dimensional change and deterioration of resin materials.

3) When storing the opened product, please be careful not to allow foreign matter to adhere or mix in, and repackage it as it is. Especially nylon will change its dimensions due to moisture absorption, so please keep it sealed.
If you need moisture-proof packaging, please contact us.

4) Do not place near high temperature heat sources such as boilers and heaters. Rubber materials will deteriorate faster due to heat.

5) Do not place it near objects such as motors that easily produce ozone.

6) Do not hang with nails, iron wires, ropes, etc., which will cause the seal to deform or the tip of the lip to be injured.

7) Discoloration or white powder on the surface (blooming phenomenon) may occur during storage, but these conditions will not affect the performance.

The PTFE slip ring of the combined seal is easy to be damaged due to drop impact or external hard force. Please be careful when using it.

6....Our inventory series products includes of brand oil seal :

Pump truck accessories Italy TECNOLAN TDE50 piston combination seal

Product egory

Piston seal: TDE TPM TPL PDE PDP TTU TTD TTE TRU SPGW SPGO SPG SPGA SPF NCF ODI OSI OUIS OHM OKH DAS OK SELA OUY D-8

Rod Seal: TSE TLI TTH TTI TTS IDI IUH ISI IUIS D-2 D-3 D-6

U-seal: UPI UPH USH USI V99F V96H UN

Buffer seal: HBTS HBY HBTTS D-14

Wiper seal: DKB DKBI DKBI3 DKBZ DKI, DWI DKH DWIR DSI LBI LBH VAY DH ME-2,ME-8

Wear ring: WR KZT RYT

Rotating seal: ROI D-14 SPN

Spare ring: N4W BRT-PTFE BRT-NYLON BRT2 BRT3 BRT-G BRT-P BRN2 BRN3

O-ring: Oring kit P series G series AS series S series M 1.5 series M 2.0 series M 1.9 series M 2.4 series
M 3.0 series M4.0

Common pressure oil seals: SC, SB, TC, TB, VC, VB, DCY, TC4Y, TC4, TB4, DC, DB, VR, MG, OKC3,HSCL,HTC ,HTC9L,HTGL,KC
High pressure oil seal: TCV, TCN TCZ ,TCN-6, TZ TCHD, TCHD-1 ,ISPID, 15Z, 15Z-3...

7.... Company Profile


Guangzhou upseal technology co., ltd

8.... Picture viewing

Can you call us to discuss your questions when you have time? Please call 86 13924029131 whatsapp(wechat ).
We believe you will find some oilseals & repair kits in our product . We are confident that our products can meet your needs in various ways.
Please let us know if you want to deal with Solve the problem of seals further. look forward to hearing from you.

9.... FAQ

Q1: The product pictures raised by our store are all real product pictures. If you want to know more, please contact us.

A. In order to give you fast and accurate pricing information, we need some details about the machine
