Specifications
Supply Ability :
150 set/year
Packaging Details :
Safety Wood or Plywood Crates Packing
Model Number :
XPG-500
Brand Name :
SFC
Delivery Time :
25-35 days
Place of Origin :
Qingdao, China
MOQ :
1 set
Price :
US$20,000.00-32,000.00
Certification :
CE, ISO
Payment Terms :
T/T,L/C
Description
Rubber Sheet Batch off Cooler - XPG-900
Product Overview
Advanced rubber sheet cooling system designed for efficient temperature reduction from high temperature to room temperature. Suitable for various rubber materials with customizable configurations.
Key Specifications
Model: XPG-900
Certifications: CE, ISO9001:2015, SGS
Power: 28.8 kW
Max. Rubber Sheet Width: 900 mm
Rubber Sheet Thickness: 6-12 mm
Linear Speed of Taking-in Conveyor: 4-40 m/min
Hanging Height: 1400 mm
Production Capacity: 200 sets/month
Advanced Features
  • Steel conveying rollers with integrated printer and slitter
  • AC inverter motor drive with adjustable conveying speed
  • Dual hanging bar driving systems for intermittent movement
  • Environmentally friendly lubricator coating system
  • Fully enclosed hanging area with optimized airflow
  • Advanced robotic take-off with automatic control
  • Reliable PC-based electric control system
Design Flexibility: Available as floor or overhead construction with output options on first floor, second floor, or both. Modular design allows for customization of middle supports and cutting equipment.
Automatic Grade Rubber Sheet Batch-off Cooler with 900 mm Max. Width and Floor-Standing Type Automatic Grade Rubber Sheet Batch-off Cooler with 900 mm Max. Width and Floor-Standing Type
Technical Comparison Table
Model XPG-600 XPW-600 XPG-800 XPG-900
Structure Floor-standing Chain-Belt Overhead Overhead
Max. Width (mm) 600 600 800 900
Thickness (mm) 4-10 2-12 4-10 6-12
Cooling Fans 12 - 20 18-26
Total Power (kW) 13.7 - 28.8 18-34
Automatic Grade Rubber Sheet Batch-off Cooler with 900 mm Max. Width and Floor-Standing Type Automatic Grade Rubber Sheet Batch-off Cooler with 900 mm Max. Width and Floor-Standing Type
Manufacturer Profile
Qingdao Shun Cheong Rubber Machinery Manufacturing Co., Ltd specializes in high-technology rubber machinery production. Certified by ISO9001:2015, EU CE, and Switzerland SGS standards.
Product Range
Serving tire manufacturing, conveyor belt production, rubber products, tire refurbishing, and waste tire recycling industries with equipment including Rubber Kneaders, Mixing Machines, Vulcanizing Presses, Calenders, and Extruders.
Global Reach
Exporting to over 50 countries including USA, Germany, Brazil, India, Russia, and throughout Europe and Asia, with established reputation for quality and reliability.
Automatic Grade Rubber Sheet Batch-off Cooler with 900 mm Max. Width and Floor-Standing Type Automatic Grade Rubber Sheet Batch-off Cooler with 900 mm Max. Width and Floor-Standing Type Automatic Grade Rubber Sheet Batch-off Cooler with 900 mm Max. Width and Floor-Standing Type Automatic Grade Rubber Sheet Batch-off Cooler with 900 mm Max. Width and Floor-Standing Type
Quality Commitment
  • Strict quality inspection for all components
  • Comprehensive pre-shipment testing and trial runs
  • Free technical support for all products
  • 3-year warranty on main parts, 1-year on wearing parts
  • Rapid response service with on-site support when needed
Automatic Grade Rubber Sheet Batch-off Cooler with 900 mm Max. Width and Floor-Standing Type
Certifications
Automatic Grade Rubber Sheet Batch-off Cooler with 900 mm Max. Width and Floor-Standing Type Automatic Grade Rubber Sheet Batch-off Cooler with 900 mm Max. Width and Floor-Standing Type Automatic Grade Rubber Sheet Batch-off Cooler with 900 mm Max. Width and Floor-Standing Type
Customer Support Services
  • Custom machine design with engineering drawings
  • Production progress tracking with photo updates
  • Complete documentation package provided
  • Free technical drawings, user guides, and maintenance manuals
  • Overseas installation and operator training services
Frequently Asked Questions
Quality Control Process
Comprehensive quality control throughout production with full assembly and testing before shipment. All machines undergo rigorous performance verification.
Warranty & Service
1-year quality guarantee using world-renowned components. Overseas installation available with small machines taking 2-3 days and production lines approximately 30 days.
Trust & Verification
Established reputation with global rubber manufacturers. Factory visits welcome to verify quality and capabilities firsthand.
Contact Information
WhatsApp: +8618344700139
Email: rubbermachine@sfcjx.com
Location: Qingdao City, Shandong Province, China
Airport: Qingdao Jiaodong Airport (pickup service available)
