High Capacity Low Energy Consumption Automatic Tyre Reconditioning Vulcanizer C Type Vulcanizing Press
High Capacity Low Energy Consumption Automatic Tyre Reconditioning Vulcanizer C Type Vulcanizing Press
High Capacity Low Energy Consumption Automatic Tyre Reconditioning Vulcanizer C Type Vulcanizing Press
High Capacity Low Energy Consumption Automatic Tyre Reconditioning Vulcanizer C Type Vulcanizing Press
High Capacity Low Energy Consumption Automatic Tyre Reconditioning Vulcanizer C Type Vulcanizing Press
High Capacity Low Energy Consumption Automatic Tyre Reconditioning Vulcanizer C Type Vulcanizing Press
High Capacity Low Energy Consumption Automatic Tyre Reconditioning Vulcanizer C Type Vulcanizing Press
High Capacity Low Energy Consumption Automatic Tyre Reconditioning Vulcanizer C Type Vulcanizing Press
High Capacity Low Energy Consumption Automatic Tyre Reconditioning Vulcanizer C Type Vulcanizing Press
High Capacity Low Energy Consumption Automatic Tyre Reconditioning Vulcanizer C Type Vulcanizing Press
Specifications
Control Mode :
PLC
Certification :
1 set
Place of Origin :
Qingdao, China
Payment Terms :
T/T,L/C
Supply Ability :
60set/month
Model Number :
XLB-3000x1000x5
Packaging Details :
No Packing or as The Customer's Request
Plc :
Mitushibi, Siemens .
Brand Name :
SFC
MOQ :
1 set
Price :
US$8,000.00-35,000.00
Delivery Time :
25-35 days
Frame Form :
Column Structure
Character :
With push-pull mould
Material :
Carbon Steel/Stainless Steel
Description
High Technology Tyre Reconditioning Vulcanizer with CE & ISO
Basic Information
Model NO.: XLB
Type: C Type Vulcanizing Press
Power: 7.5-40kw
Working Layer No.: 5
Piston Diameter: Customized
Transport Package: Standard Export Packages
Specification: CE1282, ISO9001:2008, SGS
Trademark: SFC
Origin: China
HS Code: 8477800000
Product Overview
High Technology tyre reconditioning vulcanizer with CE & ISO certification, designed for efficient and reliable tyre retreading operations.
High Capacity Low Energy Consumption Automatic Tyre Reconditioning Vulcanizer C Type Vulcanizing Press High Capacity Low Energy Consumption Automatic Tyre Reconditioning Vulcanizer C Type Vulcanizing Press High Capacity Low Energy Consumption Automatic Tyre Reconditioning Vulcanizer C Type Vulcanizing Press
Key Features
  • Low energy consumption
  • Convenient maintenance
  • High capacity with simple operation
  • Automatic system control
Technical Parameters
We can design various presses according to your specific requirements.
Model XLB-3000x1000x5 XLB-5500x360x5 XLB-5500x360x5 XLB-1100x420x5
Total Pressure (MN) 12 10 8 20
Daylight (mm) 140 75 75 75
Working Layer No. 5 5 5 5
Piston Stroke (mm) 500 375 375 375
Piston Diameter (mm) φ360 φ250 φ250 φ250
Hydraulic Cylinder No. 8 10 8 20
Working Hydraulic Pressure (Mpa) 14.7 20.4 20.4 20.4
Motor Power (KW) 29.5 21.5 7.5 40
Dimension (mm) 3720X3460X4120 7600X2700X3100 7600X2700X3100 15500X3400X4200
Structure Type Jaw Side-plate Side-plate Side-plate
High Capacity Low Energy Consumption Automatic Tyre Reconditioning Vulcanizer C Type Vulcanizing Press High Capacity Low Energy Consumption Automatic Tyre Reconditioning Vulcanizer C Type Vulcanizing Press
Main Features
  • Two dual-action cylinders for fast mold open/close operation
  • Mass flow pre-fill valve for efficient performance
  • Automatic mold forward/backward movement
  • Automatic and manual switching control with emergency power failure operation
  • Multiple options for layer number and tables
  • High-quality hydraulic pressure components and electrical equipment
  • Automatic pressure compensation, exhaust, vulcanization digital display, and mold opening
  • Complete automated working cycle from mold pull-in to product pushing
  • Custom non-standard designs available according to customer requirements
High Capacity Low Energy Consumption Automatic Tyre Reconditioning Vulcanizer C Type Vulcanizing Press
Frequently Asked Questions
What does your factory do regarding quality control?
We implement comprehensive quality control throughout production. Every machine is fully assembled and carefully tested before shipment.
What's the machine quality guarantee?
Quality guarantee period is one year. We use world-famous brand components to ensure optimal working condition.
Are you able to give installation and commissioning overseas? How long will it take?
Yes, we provide overseas service and technical support. Small machines typically take 2-3 days, while large production lines require about 30 days.
How can I trust you to deliver the right machine as I ordered?
We guarantee delivery of high-quality machines as confirmed in your order. Our company culture emphasizes innovation, quality, integrity, and efficiency.
How can we visit your facility?
We are located in Qingdao City, Shandong province, China, near Qingdao Liuting Airport. We provide airport pickup service.
High Capacity Low Energy Consumption Automatic Tyre Reconditioning Vulcanizer C Type Vulcanizing Press High Capacity Low Energy Consumption Automatic Tyre Reconditioning Vulcanizer C Type Vulcanizing Press
Our Services
  • Custom machine design with engineering drawings for customer confirmation
  • Production progress tracking with regular photo updates
  • Complete documentation including packing list, commercial invoice, and bill of lading
  • Free technical documentation: foundation DWG, installation drawings, user guides, maintenance manuals, and part drawings
  • Overseas engineer service and operator training
