Water Cooling Rubber Mixing Machine with 360mm Roller Diameter and 30kw Motor Power Open Mixing Mill
Water Cooling Rubber Mixing Machine with 360mm Roller Diameter and 30kw Motor Power Open Mixing Mill
Water Cooling Rubber Mixing Machine with 360mm Roller Diameter and 30kw Motor Power Open Mixing Mill
Water Cooling Rubber Mixing Machine with 360mm Roller Diameter and 30kw Motor Power Open Mixing Mill
Water Cooling Rubber Mixing Machine with 360mm Roller Diameter and 30kw Motor Power Open Mixing Mill
Water Cooling Rubber Mixing Machine with 360mm Roller Diameter and 30kw Motor Power Open Mixing Mill
Water Cooling Rubber Mixing Machine with 360mm Roller Diameter and 30kw Motor Power Open Mixing Mill
Water Cooling Rubber Mixing Machine with 360mm Roller Diameter and 30kw Motor Power Open Mixing Mill
Specifications
Brand Name :
SFC
Certification :
CE, ISO
Place of Origin :
Qingdao, China
MOQ :
1 set
Price :
US$19,000.00-23,000.00
Payment Terms :
T/T,L/C
Delivery Time :
25-35 days
Description

Basic Info.

Model NO.
XK-300
Automatic Grade
Automatic
Power Source
Electric
Type
Open Mixing Mill
Model
Xk-360
Roller Diameter
360mm
Roller Working Length
900mm
Friction Ratio
1:1.25
Certification
ISO, CE, SGS
Motor Power
30kw
Mixing Capacity
20-25kg/Batch
Transport Package
Standard Packing
Specification
CE, ISO9001: 2008, SGS
Trademark
SFC
Origin
China
HS Code
84778000
Production Capacity
300 Sets/Year

Product Description

Rubber Compound Mixing Machine, Water Cooling Rubber Mixing Machine

 Item XK-160 XK-250 XK-360 XK-400 XK-450 XK-550 XK-560 XK-660 XK-710
Roll diameter mm 160 250 360 400 450 550 560-510 660 710
Roll working length
320 620 900 1000 1200 1500 1530 2130 2200
Front roll linear speed r/min 9 16.3 16.7 19.3 21.8 22.5 27.2 28 31.9
Speed ratio of rolls
01: 01.4 01: 01.1 01: 01.3 01: 01.3 01: 01.3 01: 01.2 01: 01.2 01: 01.2 01: 01.5
Max roll space mm 4.5 8 10 10 12 16 15 0.5-15 0.5-15
Compound feeding capacity kg 1-2 10-15 20-25 18-35 50 50-65 50-65 165 190
Motor power kW 5.5 18.5 30 45 55 110 90 240 280
Dimensions(L× W× H)









L mm 1133 2722 4200 4920 5405 6646 6270 7280 8185
W mm 920 1115 1780 1780 1740 2736 2282 3400 3910
H mm 1394 1345 1760 1800 1790 2105 2000 2530 2270
Gross weight T ~2 ~3.2 ~6.5 ~8 ~11.4 ~22 ~22.5 ~49 ~51

Main Features: Low noise, high working efficiency, lower power consumption and longer life service.

The main introduction of this XK-450 mixing mill:

Water Cooling Rubber Mixing Machine with 360mm Roller Diameter and 30kw Motor Power Open Mixing Mill
Water Cooling Rubber Mixing Machine with 360mm Roller Diameter and 30kw Motor Power Open Mixing Mill
Water Cooling Rubber Mixing Machine with 360mm Roller Diameter and 30kw Motor Power Open Mixing Mill
Water Cooling Rubber Mixing Machine with 360mm Roller Diameter and 30kw Motor Power Open Mixing Mill
1. The rubber mixing mill is made of LTG-H alloy chilled cast iron.

2. The mixing mill speed reducing machine adopts hard tooth, its running noise is low and owns long life. This mixing mill adopts a special design of refining seal structure so that it can eliminate the leakage of lubricating oil.

3. Our Company specially designed the human-orientated machine, such as block rubber board and turbine tapping rubber device of open mixing mill can be used steam style; Open mixing mill control system is design nearby the working areas etc.

4. This mixing mill can be equipped with hydraulic or mechanical rubber blender device which can automatically make the rubber material be mixed over and over again, so the labor intensity and mixing time can be reduced greatly.

5. The roller nip of the mixing mill can be adjusted by using manual or electrical mode

6. To ensure the safety of staff and equipment, we install convenient buttons for emergency stop.

7. All the mixing mills we provide to you are checked through 8 hours non-stop full load operation, customers can use them immediately after installation.

Notes: If you have any other requests about this mixing mill, we will try our best to produce the mixing mill according to your requirements.
