Rubber Tile Vulcanizing Press/ Cheap Hydraulic Press for Rubber Tile / Rubber Machine/Floor Tile Making Machine
Rubber Tile Vulcanizing Press/ Cheap Hydraulic Press for Rubber Tile / Rubber Machine/Floor Tile Making Machine
Rubber Tile Vulcanizing Press/ Cheap Hydraulic Press for Rubber Tile / Rubber Machine/Floor Tile Making Machine
Rubber Tile Vulcanizing Press/ Cheap Hydraulic Press for Rubber Tile / Rubber Machine/Floor Tile Making Machine
Rubber Tile Vulcanizing Press/ Cheap Hydraulic Press for Rubber Tile / Rubber Machine/Floor Tile Making Machine
Rubber Tile Vulcanizing Press/ Cheap Hydraulic Press for Rubber Tile / Rubber Machine/Floor Tile Making Machine
Rubber Tile Vulcanizing Press/ Cheap Hydraulic Press for Rubber Tile / Rubber Machine/Floor Tile Making Machine
Rubber Tile Vulcanizing Press/ Cheap Hydraulic Press for Rubber Tile / Rubber Machine/Floor Tile Making Machine
Rubber Tile Vulcanizing Press/ Cheap Hydraulic Press for Rubber Tile / Rubber Machine/Floor Tile Making Machine
Rubber Tile Vulcanizing Press/ Cheap Hydraulic Press for Rubber Tile / Rubber Machine/Floor Tile Making Machine
Rubber Tile Vulcanizing Press/ Cheap Hydraulic Press for Rubber Tile / Rubber Machine/Floor Tile Making Machine
Rubber Tile Vulcanizing Press/ Cheap Hydraulic Press for Rubber Tile / Rubber Machine/Floor Tile Making Machine
Specifications
Brand Name :
SFC
Model Number :
XLB-D1000*1000
Certification :
CE, ISO
Place of Origin :
Qingdao, China
MOQ :
1 set
Price :
US$5,000.00-50,000.00
Payment Terms :
T/T,L/C
Supply Ability :
150 set/year
Delivery Time :
25-35 days
Description
Rubber Tiles Vulcanizing Press with 4 Working Layers
High-performance vulcanizing press designed for rubber bricks and tiles production, featuring 1000x1000mm platen size and manual push-out device.
Product Overview
Model: XLB-D550X550X4 Rubber Tiles Vulcanizing Press with 4 Working Layers
Rubber Tile Vulcanizing Press/ Cheap Hydraulic Press for Rubber Tile / Rubber Machine/Floor Tile Making Machine
Certifications & Quality Standards
ISO 9001:2008, CE, SGS certified
Key Features
  • Oil-free operation system for cleaner production
  • Enhanced rubber heat resistance technology
  • Specialized for rubber bricks and tiles production
  • Customizable tonnage and dimensions available
  • One-year comprehensive warranty included
Technical Specifications
Parameter/Type XLB-D550*550*4 XLB-D650*650*2
Total Pressure (MN) 0.5 1.35
Platen Size (mm) 550*550 (Q235) 650*650 (Q235)
Daylight (mm) 150 200
Daylight No. 4 2
Piston Stroke (mm) 400 400
Motor Power (KW) 3.0 3.0
Overall Size (mm) 2200*900*2200 2200*1200*2400
Weight (kg) 3600 5000
Production Capabilities
4 working layers producing 8 rubber floor pieces per hour. Manual push-out device included. Compatible with molds from 20mm to 75mm thickness.
Additional Equipment
Rubber mixer available upon request. Complete setup with 12 molds and rubber mixer requires only 8m³ floor space.
Rubber Tile Vulcanizing Press/ Cheap Hydraulic Press for Rubber Tile / Rubber Machine/Floor Tile Making Machine
After-Sales Service
  • Comprehensive 3-7 hour load testing before shipment
  • One-year guarantee with free replacement for damaged components
  • Remote technical support via email and online communication
  • Regular customer follow-up and maintenance tracking
Manufacturer Profile
Qingdao Shun Cheong Rubber Machinery Manufacturing Co., Ltd. - Established in 2007 with over 10 years of expertise in rubber machinery manufacturing. ISO 9001:2008, SGS, and CE certified.
Product Range
Rubber kneaders, mixing mills, plate vulcanizing presses, rubber calenders, batch off coolers, waste tire recycling lines, reclaimed rubber production lines, conveyor belt production lines, and rubber seals extruding & vulcanizing lines.
Global Reach
Machinery exported to America, Mexico, India, Vietnam, South Africa, Singapore, Malaysia, Indonesia, Australia, Sri Lanka and other regions worldwide.
