Specifications
Brand Name :
SFC
Model Number :
XLB
Certification :
CE, ISO
Place of Origin :
Qingdao, china
MOQ :
1 set
Price :
US$2,300.00-3,300.00
Payment Terms :
T/T,L/C
Supply Ability :
900set/year
Delivery Time :
25-35 days
Packaging Details :
Standard Packaging
Description
Product Overview of High Quality EPDM Rubber Floor Vulcanizing Press Machine
XLB Model Rubber Tile Production Line / EPDM Rubber Floor Vulcanizing Press Machine for curing rubber tiles and mats using recycled rubber materials.
High Quality EPDM Rubber Floor Vulcanizing Press Machine High Quality EPDM Rubber Floor Vulcanizing Press Machine High Quality EPDM Rubber Floor Vulcanizing Press Machine
Key Features of High Quality EPDM Rubber Floor Vulcanizing Press Machine
  • Column type construction with hydraulic cylinder, piston, column, hot plate, track, mould, top link, hydraulic station, and electric cabinet
  • Manual push-out device with two sets of moulds for high production efficiency
  • Adjustable mould thickness from 20mm to 75mm
  • Optional mixer equipment available upon request
Quality Construction
Steel Plate Material
High-quality carbon steel Q-235 from Jigang Group Co., Ltd with thicker construction, shot blasting treatment for smooth surface and superior strength.
Frame Weldment
World-class welding techniques including carbon dioxide gas shielded welding with alloyed welding wire, submerged arc welding, and VSR treatment after weldment with stewing fire treatment.
Piston Construction
Chilled cast iron plunger material with polishing, grinding treatment, and compression testing for smooth, anti-abrasion surface.
Heating & Temperature Control
Heating options: Steam, oil, or electric with high-quality heating pipes for stability
Temperature range: 0-300°C (customizable to 400°C upon request)
Precise plate temperature tolerance: ±0.1°C
Optional water cooling system available
Hydraulic System
PLC controlled with professional hydraulic components for stable and reliable operation. Pressure sensor control system maintains constant pressure.
Technical Specifications of EPDM Rubber Floor Vulcanizing Press Machine
Type XLB-D550x550x2 XLB-D660x660x2 XLB-D1200x1200x2
Total Pressure (MN) 0.50 1.00 3.15
Plate Size (mm) 550 660x660 1200x1200
Working Layer Number 4 2 2(4)
Piston Stroke (mm) 400 250 250(500)
Motor Power (kw) 3 3 5.5
Weight (kg) 3600 3500 9500
High Quality EPDM Rubber Floor Vulcanizing Press Machine High Quality EPDM Rubber Floor Vulcanizing Press Machine High Quality EPDM Rubber Floor Vulcanizing Press Machine
Custom Manufacturing
We design and manufacture various kinds of non-standard rubber machinery according to client's specific requirements.
High Quality EPDM Rubber Floor Vulcanizing Press Machine High Quality EPDM Rubber Floor Vulcanizing Press Machine High Quality EPDM Rubber Floor Vulcanizing Press Machine High Quality EPDM Rubber Floor Vulcanizing Press Machine
Company Capabilities
Professional technology R&D institution with CAD-aided design. Our machines are exported worldwide including United States, Chile, Europe, Africa, Southeast Asia, and the Middle East.
Product Range
  • Mixing Equipment: Rubber Kneader, Two Roll Mill, Rubber Sheeting Mill, Rubber Refining Mill, Rubber Crusher
  • Curing Equipment: Pillar/Frame Type Plate Vulcanizing Press, Duplex Curing Press, Rubber Tiles Vulcanizing Press, Jaw Vulcanizing Press Machine, Large Plate Vulcanizing Machine, Automatic Plate Vulcanizing Molding Machine
  • Extruding Equipment: Hot Feed Extruder, Rubber Strainer, EPDM Rubber Extrusion & Vulcanizing Line
  • Calender Equipment: Two Roll Calender, Three Roll Calender, Four Roll Calender, Inner Liner & Rubber Calender Line
  • Waste Tires Recycling Equipment: Semi-automatic and Full-automatic Waste Tires Recycling Lines, Fine Rubber Powder Pulverizer
  • Other Equipment: Reclaimed Rubber Production Line, Batch-Off Cooler, Conveyor Belt Splicing Press
