Specifications
Brand Name :
SFC
Model Number :
XLB-1200*1200*2
Certification :
CE, ISO
Place of Origin :
Qingdao, China
MOQ :
1 set
Price :
US$10,000.00-17,000.00
Payment Terms :
T/T,L/C
Supply Ability :
60set/month
Delivery Time :
25-35 days
Packaging Details :
No Packing or as The Customer's Request
Automatic Grade :
Automatic
Total Pressure(Mn) :
315
Working Layer No. :
2
Type :
General Rubber Machinery
Customized :
Customized
Structure :
Horizontal
Plate Distance(mm) :
200
Plate Unit Area Pressure(MPa) :
22
Piston Stroke(mm) :
400
Plate Size(mm) :
1200*1200
Description

Product Description

Frame Type Plate Rubber Vulcanizer Machine/ Vulcanizing Press (XLB-DQ1200*1200*2)

Product Description

Frame Type Plate Rubber Vulcanizer Machine/ Vulcanizing Machine (XLB-DQ1200*1200*2):
1. CE, SGS, ISO9001: 2008 certification
2. PLC control, high production efficiency
3. Low noise, high safety and convenient
4. High speed in open/close mold
5. Competitive price
6. Customizable

Frame Type Large Platen Rubber Vulcanizer/rubber Curing Press/hydraulic Type Curing Press Of Rubber Product
Frame Type Large Platen Rubber Vulcanizer/rubber Curing Press/hydraulic Type Curing Press Of Rubber Product
Feature:
This vulcanizing machine is used for all kinds of vulcanizing mould, rubber and plastic mouldproducts, and non-mould products.

Being a column structure and downward pressing type, the heating plate opens by the self-weight of the heating plate, platform and plunger. The rising of the plunger makes the heating plate close while the hydraulic oil provides the pressure.

This engine base is combined together with the cylinder and base frane, which is made of ductile iron to increase the cylinder intensity and a brad ablility. The cylinder is fitted with the sealing washer made of the oil-resisting rubber for the sealing purpose.

By moving the operational handle of the control valve to the two different posistions, the heating plate can open and clsoe.

It uses the electric pipe for heating, thus makes the workshop clean with easy and reliable operation.

Note:
We can design and manufacture all kinds of non-standard rubber machinery according to the requirement of the customers.

Main Parameter
Type XLB-DQ1200× 1200× 2 XLB-DQ1300× 2000× 1 XLB-Q1200× 2500× 1 XLB-Q1500× 2000× 1 XLB-Q2000× 3000× 1 XLB-Q1400× 5700× 1
Total Pressure(MN) 315t 560t 750t 1000t 1800t 2800t
Plate Size(mm) 1200× 1200 1300× 2000 1200× 2500 1500× 2500 2000× 3000 1400× 5700
Daylight (mm) 200 400 400 400 400 400
Layer NO. 2 1 1 1 1 1
Piston Stroke(mm) 400 400 400 400 400 400
Plate Unit Area Pressure 22 21.5 25 33.5 30 35
Main Motor Power(kw) 3 8 9.5 11 26 43.5
Overall Dimension(L× W× H) (mm) 1685× 1320× 2450 2000× 1860× 2500 2560× 1700× 2780 2810× 1550× 3325 2900× 3200× 2860 2400× 5800× 3600
Weight(kg) 9500 17000 20000 24000 66000 110000

Frame Type Large Platen Rubber Vulcanizer/rubber Curing Press/hydraulic Type Curing Press Of Rubber Product
Frame Type Large Platen Rubber Vulcanizer/rubber Curing Press/hydraulic Type Curing Press Of Rubber Product
Frame Type Large Platen Rubber Vulcanizer/rubber Curing Press/hydraulic Type Curing Press Of Rubber Product
Packaging

Equipment painting completed before delivery, and then wrapped with stretch film, avoid rubbing the paint off the surface, wooden packaging can be customized, key parts, such as electronic control box, will be wrapped by shockproof packaging materials, and then packed in wooden cases.

Frame Type Large Platen Rubber Vulcanizer/rubber Curing Press/hydraulic Type Curing Press Of Rubber Product
FAQ

1. What does your factory do regarding quality control?
We pay much more importance to quality control from the very beginning to the end of production. Every machine will be fully assembled and carefully tested before shipment.

2. What's the machine quality guarantee?
Quality guarantee time is one year.We choose world famous brand components to keep our machine in perfect working condition.

3. Are you able to give installation and commissioning overseas?How long time will it take?
Yes, we can supply overseas service and technical support but customer needs to pay for the cost of the installation. Small machine usually takes within 2~3 days. Big production line usually takes about 30 days.

4. How can I trust you to deliver the right machine as I ordered?
We will absolutely deliver a good quality machine as we discussed and confirmed in the order. The core of our company culture is innovation,quality,integrity and efficiency. Also we have had many good cooperation with world famous rubber production manufacturers.

If you come to our factory, we can show the user around us.

5. How can we go to your side?

We are located in Qingdao City, Shandong province, China. The name of airport is Qingdao Jiaodong airport. We will pick up you at the airport.

Before leaving factory, this plate vulcanizing press needs to pass 24 hours' pressure test, pressure maintaining to test the bearing of the hydro-cylinder and piston stroke and guarantee no oil leakage and seeping to avoid unnecessary quality problems.
