EVA Foaming Vulcanizing Press, Rubber Machine, Foaming Sheet Rubber Press, EVA Foaming
EVA Foaming Vulcanizing Press, Rubber Machine, Foaming Sheet Rubber Press, EVA Foaming
Specifications
Brand Name :
SFC
Model Number :
XLB-1200X1200X4
Certification :
CE, ISO
Place of Origin :
Qingdao, China
MOQ :
1 set
Price :
US$10,000.00-5000.00
Payment Terms :
T/T,L/C
Supply Ability :
900 set/year
Delivery Time :
25-35 days
Principle :
High-Pressure Air Type
Export Markets :
Global
Automation :
Automatic
Description
EVA Foaming Vulcanizing Press with 1200x1200mm Platen Size
Professional rubber processing equipment for EVA foam production with automatic operation and CE/ISO9001:2008 certification.
Technical Specifications
Model: XLB-1200X1200X4
Total Pressure: 5MN
Motor Power: 18.5KW
Platen Size: 1200*1200mm
Daylight: 150mm
Automation: Automatic
Certification: CE, ISO9001:2008
EVA Foaming Vulcanizing Press, Rubber Machine, Foaming Sheet Rubber Press, EVA Foaming
Key Features
  • High quality plate press with beautiful modeling and compact structure
  • High speed open/close mold for increased production efficiency
  • Simple structure with wide application range and easy operation
  • Available with hand control or electric control systems
  • Small temperature difference and reliable pressure performance
  • Automatic pressure compensation during curing process
  • Low operation height designed for ergonomic use
  • Rapid mold opening with toggle mechanism
  • Energy saving design with space-saving configuration
Applications
This machine is primarily used for manufacturing EVA foam products including: slippers, foam sheets, insulation materials, sports protective gear, life jackets, sponges, mid-soles, rainboots, sandals, clogs, and various shoe accessories.
Technical Parameters
Parameter/Type XLB-Q 1200x1200x4 XLB-Q 1400x1500x6 XLB-Q 1500x1500x6
Total Pressure (MN) 5.0 8.0 10.0
Plate Size (mm) 1200*1200 1400*1500 1500*1500
Plate Clearance (mm) 150 150 150
Piston Stroke (mm) 500 800 150
Plate Unit Pressure (Mpa) 3.4 3.8 4.5
Main Motor Power (KW) 18.5 26 33
Dimension (mm) 2400*2100*3200 2650*2400*3600 2750*2400*3600
Weight (kg) 22000 38000 48000
EVA Foaming Vulcanizing Press, Rubber Machine, Foaming Sheet Rubber Press, EVA Foaming
Operational Notes
  • Clamping force adjustable from 150 to 210 tons based on requirements
  • Fully hydraulic automatic operation with PLC control system
  • Humanized parameter computer interface for precise production control
  • Available for 2-plate molds with thickness adjustment scope: 100-200mm
  • No water circulation required for mold station
Contact Information
WhatsApp: +8618344700139
Email: rubbermachine@sfcjx.com
Origin: Jiaonan, Qingdao, China
Production Capacity: 200 Sets/Year
Qingdao Shun Cheong Machinery Co., Ltd provides first-class technology, quality service, and cost-effective rubber processing equipment for domestic and international customers.
