Frame Structure Rubber Vulcanizing Hydraulic Press Rubber Molding Machine
Frame Structure Rubber Vulcanizing Hydraulic Press Rubber Molding Machine
Frame Structure Rubber Vulcanizing Hydraulic Press Rubber Molding Machine
Frame Structure Rubber Vulcanizing Hydraulic Press Rubber Molding Machine
Frame Structure Rubber Vulcanizing Hydraulic Press Rubber Molding Machine
Frame Structure Rubber Vulcanizing Hydraulic Press Rubber Molding Machine
Frame Structure Rubber Vulcanizing Hydraulic Press Rubber Molding Machine
Frame Structure Rubber Vulcanizing Hydraulic Press Rubber Molding Machine
Frame Structure Rubber Vulcanizing Hydraulic Press Rubber Molding Machine
Frame Structure Rubber Vulcanizing Hydraulic Press Rubber Molding Machine
Frame Structure Rubber Vulcanizing Hydraulic Press Rubber Molding Machine
Frame Structure Rubber Vulcanizing Hydraulic Press Rubber Molding Machine
Specifications
Condition :
New
MOQ :
1 set
Material :
Aluminum alloy
Brand Name :
SFC
Warranty :
1 Year
Delivery Time :
25-35 days
Packaging Details :
No Packing or as The Customer's Request
Supply Ability :
699set/year
Place of Origin :
Qingdao, China
Price :
US$6,000.00-20,000.00
Payment Terms :
T/T,L/C
Model Number :
XLE-Q1250×2050
Certification :
CE, ISO
Description
Plate Vulcanizing Press / Jaw-Type Vulcanizing Press
Product Overview

The Plate Vulcanizing Press, also known as Rubber Vulcanizing Press, is specialized equipment used for rubber vulcanization processes. This machine chemically treats raw rubber to enhance its strength, hardness, and durability.

Frame Structure Rubber Vulcanizing Hydraulic Press Rubber Molding Machine Frame Structure Rubber Vulcanizing Hydraulic Press Rubber Molding Machine
Key Applications
  • Strengthens raw rubber through chemical treatment processes
  • Enhances rubber hardness and strength characteristics
  • Essential for testing rubber strength and durability
  • Widely used in manufacturing cords, cables, and heat-resistant rubber products
Technical Specifications
Parameter / Specification XLE-Q1250*2050 XLE-Q1000*1400
Clamp Capacity (MN) 10.00 4.800
Hot Plate Specification (mm) 1250*2050 1000*1400
Space Between (mm) 450 400
Plunger Diameter Φ650 Φ450
Maximum Working Hydraulic Pressure (Mpa) 15 15
Compressed Air Pressure (Mpa) 0.6-0.8 0.6-0.8
Maximum Steam Pressure (Mpa) 1.0 1.0
Electric Machine Power (kw) 15 15
Overall Dimension (mm) 1300*800*1500 2500*1400*3330
Weight (kg) 45000 23000
Frame Structure Rubber Vulcanizing Hydraulic Press Rubber Molding Machine
Key Features
• Dual-action cylinders for fast mold open/close operations
• Mass flow pre-fill valve for efficient performance
• Automatic mold forward/backward movement
• Automatic and manual switching control with power failure safety
• Multiple layer number and table configuration options
• Imported hydraulic components and electrical equipment for reliability
• Advanced automation including pressure compensation, automatic exhaust, and digital vulcanization display
• Complete automated working cycle from mold pull-in to product pushing
• Custom non-standard designs available according to customer requirements
Frame Structure Rubber Vulcanizing Hydraulic Press Rubber Molding Machine
Quality Assurance

Every plate vulcanizing press undergoes rigorous 24-hour pressure testing before leaving our factory. This includes pressure maintaining tests to verify hydro-cylinder bearing capacity, piston stroke accuracy, and ensure no oil leakage or seepage issues.

Frequently Asked Questions
Quality Control Process

We implement comprehensive quality control throughout production. Every machine is fully assembled and carefully tested before shipment to ensure optimal performance.

Quality Guarantee

One-year quality guarantee with world-famous brand components to maintain perfect working condition.

Overseas Installation Support

We provide overseas installation and commissioning services with technical support. Small machines typically require 2-3 days, while large production lines take approximately 30 days.

Order Accuracy Assurance

We guarantee delivery of exactly what was ordered and confirmed. Our company culture emphasizes innovation, quality, integrity, and efficiency, with proven collaborations with world-renowned rubber manufacturers.

Factory Location

Located in Qingdao City, Shandong province, China. We provide airport pickup services from Qingdao Liuting International Airport.

Frame Structure Rubber Vulcanizing Hydraulic Press Rubber Molding Machine Frame Structure Rubber Vulcanizing Hydraulic Press Rubber Molding Machine
