Specifications
Brand Name :
SFC
Model Number :
XLB
Certification :
CE, ISO
Place of Origin :
Qingdao, China
MOQ :
1 set
Price :
US$2,300.00-3,300.00
Payment Terms :
T/T,L/C
Supply Ability :
890 set/year
Delivery Time :
25-35 days
Description
Floor Tile Vulcanizer / Rubber Tile Vulcanizing Press
Semiautomatic rubber vulcanizing press machine for curing rubber tiles and mats using recycled rubber materials. Features 1200x1200 mm platen size with 2 or 4 working layers.
Product Specifications
ModelXLB
CertificationCE, ISO, SGS
StructureHorizontal
Working Layers2 or 4 Layer
Platen Size1200×1200 mm
Automatic GradeSemiautomatic
Production Capacity50 Sets/Year
OriginQingdao, China
Semiautomatic Rubber Vulcanizing Press Machine with 1200x1200 mm Platen Size and 2 or 4 Working Layers for Rubber Tile Production Semiautomatic Rubber Vulcanizing Press Machine with 1200x1200 mm Platen Size and 2 or 4 Working Layers for Rubber Tile Production Semiautomatic Rubber Vulcanizing Press Machine with 1200x1200 mm Platen Size and 2 or 4 Working Layers for Rubber Tile Production
Key Features
  • Column type construction with hydraulic cylinder, piston, column, hot plate, track, and mould
  • Manual push-out device with two sets of moulds for high production efficiency
  • Adjustable mould thickness from 20mm to 75mm
  • Optional mixer equipment available
  • High-quality Q-235 carbon steel construction with shot blasting treatment
  • Professional welding techniques including carbon dioxide gas shielded welding
  • Chilled cast iron piston with polishing and grinding treatment
  • Precise temperature control with ±0.1°C tolerance
  • PLC controlled hydraulic system with pressure sensor
Technical Specifications
Type XLB-D550×550×2 XLB-D660×660×2 XLB-D1200×1200×2
Total Pressure (MN) 0.50 1.00 3.15
Plate Size (mm) 550 660×660 1200×1200
Working Layers 4 2 2(4)
Piston Stroke (mm) 400 250 250(500)
Motor Power (kw) 3 3 5.5
Weight (kg) 3600 3500 9500
Semiautomatic Rubber Vulcanizing Press Machine with 1200x1200 mm Platen Size and 2 or 4 Working Layers for Rubber Tile Production Semiautomatic Rubber Vulcanizing Press Machine with 1200x1200 mm Platen Size and 2 or 4 Working Layers for Rubber Tile Production Semiautomatic Rubber Vulcanizing Press Machine with 1200x1200 mm Platen Size and 2 or 4 Working Layers for Rubber Tile Production
Heating & Temperature Control
Steam, oil, or electric heating options available. Temperature range: 0-300°C (extendable to 400°C). Advanced water cooling system available.
Custom Manufacturing
We design and manufacture various kinds of non-standard rubber machinery according to client requirements.
Semiautomatic Rubber Vulcanizing Press Machine with 1200x1200 mm Platen Size and 2 or 4 Working Layers for Rubber Tile Production Semiautomatic Rubber Vulcanizing Press Machine with 1200x1200 mm Platen Size and 2 or 4 Working Layers for Rubber Tile Production Semiautomatic Rubber Vulcanizing Press Machine with 1200x1200 mm Platen Size and 2 or 4 Working Layers for Rubber Tile Production Semiautomatic Rubber Vulcanizing Press Machine with 1200x1200 mm Platen Size and 2 or 4 Working Layers for Rubber Tile Production
Company Capabilities
Professional R&D institution using CAD-aided design. Our machines are exported worldwide including United States, Chile, Europe, Africa, Southeast Asia, and Middle East.
Product Range
Mixing Equipment
Rubber Kneader, Two Roll Mill, Rubber Sheeting Mill, Rubber Refining Mill, Rubber Crusher
Curing Equipment
Pillar/Frame Type Plate Vulcanizing Press, Duplex Curing Press, Jaw Vulcanizing Press Machine, Large Plate Vulcanizing Machine
Extruding Equipment
Hot Feed Extruder, Rubber Strainer, EPDM Rubber Extrusion & Vulcanizing Line
Calender Equipment
Two Roll Calender, Three Roll Calender, Four Roll Calender, Inner Liner & Rubber Calender Line
Waste Tires Recycling Equipment
Semi-automatic and Full-automatic Waste Tires Recycling Lines
Other Equipment
Reclaimed Rubber Production Line, Batch-Off Cooler, Conveyor Belt Splicing Press
