Automatic Open Mill Hydraulic Stock Blender Type Two Roll Rubber Mixing Mill
Automatic Open Mill Hydraulic Stock Blender Type Two Roll Rubber Mixing Mill
Automatic Open Mill Hydraulic Stock Blender Type Two Roll Rubber Mixing Mill
Automatic Open Mill Hydraulic Stock Blender Type Two Roll Rubber Mixing Mill
Automatic Open Mill Hydraulic Stock Blender Type Two Roll Rubber Mixing Mill
Automatic Open Mill Hydraulic Stock Blender Type Two Roll Rubber Mixing Mill
Automatic Open Mill Hydraulic Stock Blender Type Two Roll Rubber Mixing Mill
Automatic Open Mill Hydraulic Stock Blender Type Two Roll Rubber Mixing Mill
Automatic Open Mill Hydraulic Stock Blender Type Two Roll Rubber Mixing Mill
Automatic Open Mill Hydraulic Stock Blender Type Two Roll Rubber Mixing Mill
Specifications
Brand Name :
SFC
Model Number :
XK-560
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1
Price :
US$5,000.00-20,000.00
Payment Terms :
T/T,L/C
Supply Ability :
50set/month
Delivery Time :
25-35
Packaging Details :
as The Customer's Request
Model :
XK-560
Roller Diameter :
560mm
Speed Ratio :
1:1.2
Motor Power (KW) :
90
Roller Length :
1530mm
Voltage :
380V
Front Roll Linear Speed :
27.2(R/Min)
Auto :
Automatic
Description
Rubber Two Roller Open Mixing Mill
Product Overview

Professional rubber mixing mill, also known as rubber mill, two roll mill, open rubber mixing mill, or rubber mixer, designed for efficient rubber compound processing.

Key Features
  • Tailored and compact structure for easy operation
  • Multiple speed options and speed ratios to meet various formula requirements
  • Annealed frame, frame cap, and base for stress relief and durability
  • Chilled alloy cast iron rolls with excellent abrasion resistance
  • Class 6 precision hard-tooth surface gear reducer for long service life
  • Comprehensive emergency stop system for operator safety
  • Special seal design to prevent lubricating oil leakage
  • Easy-clean stock pan with dislodging device
  • Ergonomic operating system to reduce labor intensity
  • Modular structure offering flexible configuration options
Technical Specifications
Item XK-160 XK-250 XK-360 XK-400 XK-450 XK-550 XK-560 XK-660 XK-710
Roll diameter (mm) 160 250 360 400 450 550 560-510 660 710
Roll working length (mm) 320 620 900 1000 1200 1500 1530 2130 2200
Front roll linear speed (r/min) 9 16.3 16.7 19.3 21.8 22.5 27.2 28 31.9
Speed ratio of rolls 1:1.4 1:1.1 1:1.3 1:1.3 1:1.3 1:1.2 1:1.2 1:1.2 1:1.5
Max roll space (mm) 4.5 8 10 10 12 16 15 0.5-15 0.5-15
Compound feeding capacity (kg) 1-2 10-15 20-25 18-35 50 50-65 50-65 165 190
Motor power (kW) 5.5 18.5 30 45 55 110 90 240 280
Dimensions L*W*H (mm) 1133*920*1394 2722*1115*1345 4200*1780*1760 4920*1780*1800 5405*1740*1790 6646*2736*2105 6270*2282*2000 7280*3400*2530 8185*3910*2270
Gross weight (T) ~2 ~3.2 ~6.5 ~8 ~11.4 ~22 ~22.5 ~49 ~51
Packaging & Delivery

Equipment is painted before delivery and wrapped with stretch film to protect the surface finish. Custom wooden packaging available. Key components including electronic control boxes are protected with shockproof materials and packed in wooden cases.

Quality Assurance

Comprehensive quality control throughout production. Every machine undergoes full assembly and rigorous testing before shipment. One-year quality guarantee with world-renowned brand components for reliable performance.

Technical Support

Overseas installation and commissioning services available. Small machines typically installed within 2-3 days, production lines within approximately 30 days. Free technical documentation including foundation drawings, installation guides, maintenance manuals, and parts drawings provided.

Contact Information
Name: Sharmin khatun
WhatsApp: +8618344700139
Email: rubbermachine@sfcjx.com
Product Images
Automatic Open Mill Hydraulic Stock Blender Type Two Roll Rubber Mixing Mill Automatic Open Mill Hydraulic Stock Blender Type Two Roll Rubber Mixing Mill Automatic Open Mill Hydraulic Stock Blender Type Two Roll Rubber Mixing Mill Automatic Open Mill Hydraulic Stock Blender Type Two Roll Rubber Mixing Mill Automatic Open Mill Hydraulic Stock Blender Type Two Roll Rubber Mixing Mill
