Specifications
Brand Name :
SFC
Model Number :
XK-400
Certification :
ISO9001/CE/SGS
Place of Origin :
China
MOQ :
1
Price :
5000-60000.00USD per Set
Payment Terms :
T/T
Supply Ability :
50 Sets per Month
Delivery Time :
40 days
Packaging Details :
Standard packaging.
Roller (D*L) (mm) :
Φ400X1000
Front Roller Linear Speed (m/min) :
18.65
Friction Ratio :
1:1.27
Motor Power (KW) :
37
Overall Dimension (L*W*H) (mm) :
4350X1850X1785
Warranty :
1 Year
Description
XK-400 Two Roll Rubber Mixing Mill Machine with Preferential Price
XK-400 Two Roll Rubber Mixing Mill Machine / Rubber Open Mixing Mill / Mixing Mill For Rubber / Qingdao Open Mixing Mill
Product Introduction
  • Auto feeding oil or grease lubrication, it is easy to maintain and protect machine
  • Human nature designed controlling system ensure labor safety
  • Methods of adjusting roll nip: manual or electric
Salient Features
  • Superior Mixing Performance
  • Low Operating Cost with High Productivity
  • Compact Construction, maximum Floor Utilization
  • Latest Technology Update, Meets Current World Standards
  • Maintenance Free
  • Reliable and Experiences Service Back Up
  • Easy to Install & Ready to Run
  • No continuous Lubrication hence heavy saving on lubrication cost, wear & tear and maintenance
  • Auto reversing electric Panel
  • Simple & easy maintenance
Technical Specifications
  • Roller Material: Chilled Alloy Cast Iron
  • Roller Hardness: 68-75 HRC
  • Gear Material Hardness: 65-70 HRC
  • Cooling System: Water Cooling
  • Control Mode: Manual or automatic optional
  • Compact Structure, Low noise
  • Different types of reducer available
XK-400 Two Roll Rubber Mixing Mill with Φ400X1000 Roller 18.65 m/min Front Roller Speed and 1 Year Warranty XK-400 Two Roll Rubber Mixing Mill with Φ400X1000 Roller 18.65 m/min Front Roller Speed and 1 Year Warranty XK-400 Two Roll Rubber Mixing Mill with Φ400X1000 Roller 18.65 m/min Front Roller Speed and 1 Year Warranty XK-400 Two Roll Rubber Mixing Mill with Φ400X1000 Roller 18.65 m/min Front Roller Speed and 1 Year Warranty XK-400 Two Roll Rubber Mixing Mill with Φ400X1000 Roller 18.65 m/min Front Roller Speed and 1 Year Warranty XK-400 Two Roll Rubber Mixing Mill with Φ400X1000 Roller 18.65 m/min Front Roller Speed and 1 Year Warranty XK-400 Two Roll Rubber Mixing Mill with Φ400X1000 Roller 18.65 m/min Front Roller Speed and 1 Year Warranty XK-400 Two Roll Rubber Mixing Mill with Φ400X1000 Roller 18.65 m/min Front Roller Speed and 1 Year Warranty
Model Specifications Comparison
Model XK-230 XK-250 XK-300 XK-360 XK-400 XK-450 XK-560 XK-550B XK-660
Working Diameter of rolls (mm) 230 250 300 360 400 450 560/510 550 660
Working Length of Rolls (mm) 600 620 750 900 1000 1200 1530 1500 2130
Front Roll Surface Speed (m/min) 10.21 14.1 15.1 16.25 18.65 24.26 27.72 27.94 28.6
Friction Ratio 1:1.19 1:1.17 1:1.25 1:1.25 1:1.27 1:1.2 1:1.22 1:1.24 1:1.09
Max. nip (mm) 7 8 10 10 10 15 15 15 15
Capacity per Batch(kg) 6-10 8-15 15-20 20-25 18-35 25-50 35-50 50-60 165
Motor Power (kw) 15 18.5 22 30 37 55 90 110 245
Dimensions L (mm) 2800 3400 3400 3780 4350 5200 5845 5870 7465
Dimensions W (mm) 1200 1500 1500 1850 1850 2380 2284 2475 3662
Dimensions H (mm) 1120 1500 1550 1750 1785 1840 1978 2045 2080
Packing and Shipping
Equipment painting completed before delivery, and then wrapped with stretch film, avoid rubbing the paint off the surface, wooden packaging can be customized, key parts, such as electronic control box, will be wrapped by shockproof packaging materials, and then packed in wooden cases.
About Us
XK-400 Two Roll Rubber Mixing Mill with Φ400X1000 Roller 18.65 m/min Front Roller Speed and 1 Year Warranty XK-400 Two Roll Rubber Mixing Mill with Φ400X1000 Roller 18.65 m/min Front Roller Speed and 1 Year Warranty XK-400 Two Roll Rubber Mixing Mill with Φ400X1000 Roller 18.65 m/min Front Roller Speed and 1 Year Warranty XK-400 Two Roll Rubber Mixing Mill with Φ400X1000 Roller 18.65 m/min Front Roller Speed and 1 Year Warranty
Qingdao Shun Cheong Rubber Machinery Manufacturing Co., Ltd. is a Chinese manufacturer established in 2007, with over 10 years experience in making various rubber machines. We have passed ISO 9001:2008, SGS, and CE certifications.
Our factory specializes in rubber kneader/rubber mixing mill; various plate vulcanizing press; 2 roll/3 roll/4 roll rubber calender; rubber batch off cooler; waste tire recycling line; reclaimed rubber production line; conveyor belt production line; rubber seals extruding & vulcanizing line etc.
Our machineries have exported to America, Mexico, India, Vietnam, South Africa, Singapore, Malaysia, Indonesia, Australia, Sri Lanka and many other countries and regions.
Our Service
  • Our engineers can design target machines for customers and send them the drawing to confirm. We are always on the side of saving your cost.
  • In the process of production, we will take photos and send to customers for their track the progress.
  • Documents such as packing list, commercial invoice, and bill of lading etc. will be sent after the delivery.
  • We could supply free English foundation DWG, installation drawing, user guide, maintenance manual and part drawing.
Frequently Asked Questions
What does your factory do regarding quality control?
We pay much more importance to quality control from the very beginning to the end of production. Every machine will be fully assembled and carefully tested before shipment.
What's the machine quality guarantee?
Quality guarantee time is one year. We choose world famous brand components to keep our machine in perfect working condition.
Are you able to give installation and commissioning overseas? How long time will it take?
Yes, we can supply overseas service and technical support but customer needs to pay for the cost of the installation. Small machine usually takes within 2~3 days. Big production line usually takes about 30 days.
How can I trust you to deliver the right machine as I ordered?
We will absolutely deliver a good quality machine as we discussed and confirmed in the order. The core of our company culture is innovation, quality, integrity and efficiency. Also we have had many good cooperation with world famous rubber production manufacturers. If you come to our factory, we can show the user around us.
How can we go to your side?
We are located in Qingdao City, Shandong province, China. The name of airport is Qingdao Jiaodong airport. We will pick up you at the airport.
