Heating System Powder Solid Tire Rubber Vulcanizing Press Customization
Heating System Powder Solid Tire Rubber Vulcanizing Press Customization
Heating System Powder Solid Tire Rubber Vulcanizing Press Customization
Heating System Powder Solid Tire Rubber Vulcanizing Press Customization
Heating System Powder Solid Tire Rubber Vulcanizing Press Customization
Heating System Powder Solid Tire Rubber Vulcanizing Press Customization
Specifications
Brand Name :
SFC
Model Number :
XLB-1300x2000 x1
Certification :
CE、ISO、SGS
Place of Origin :
China
MOQ :
1
Price :
US$20000-80000
Payment Terms :
L/C, T/T
Supply Ability :
500sets/year
Delivery Time :
1 - 3(sets)40(days);>3(sets) To be negotiated
Packaging Details :
Safety wood or plywood crates packaging.
Control System :
PLC
Cylinder Stroke :
Customized
Heating Method :
Electric/Steam/Oil
Material :
Carbon Steel/Stainless Steel
Operation Mode :
Manual/Semi-automatic/Automatic
Power :
7.5-75KW
Pressure Range :
0-100MPa
Product Name :
Rubber Vulcanizing Press Machine
Size :
Customized
Temperature Range :
0-400℃
Voltage :
220V/380V/440V
Warranty :
1 Year
Weight :
Customized
Description

Heating System Powder Solid Tire Rubber Vulcanizing Press Customization


Frank Zhang
business manager
sales-8@sfcjx.com

The heating system of powder solid tire rubber vulcanizing presses is crucial for the vulcanization process. Customization options include electric heating elements, steam heating, or hot oil circulation systems. The selection of the heating system depends on factors such as energy efficiency, heating speed, and specific process requirements. The heating system should ensure uniform heat distribution throughout the mold to achieve proper curing and bonding of the rubber compound

Pressing Systems: The machines incorporate pressing systems to apply pressure to the rubber compound in the mold during vulcanization. Hydraulic or mechanical presses are commonly used for this purpose, providing the necessary force to shape and consolidate the rubber

Automation and Control: Depending on the customer's requirements, the machine can be customized with advanced automation and control features. This can include programmable logic controllers (PLCs), touch-screen interfaces, data logging capabilities, and remote monitoring options for improved operational efficiency and ease of use.

Heating System Powder Solid Tire Rubber Vulcanizing Press CustomizationHeating System Powder Solid Tire Rubber Vulcanizing Press CustomizationHeating System Powder Solid Tire Rubber Vulcanizing Press Customization


The machine employs hydraulic systems to apply pressure to the rubber plates during vulcanization. The pressure can be customized to suit the specific needs of the rubber material being processed. The hydraulic system ensures consistent and uniform pressure distribution, resulting in reliable and high-quality vulcanized rubber plates

The technical parameters for some models frame vulcanizing machines:

Product Model XLB-1300x2000 x1 XLB-1500x1500x1 XLB-1500x2500x1 XLB-2000x2000x1
Total Press (MN) 5.60 8.00 15.00 20.00
Plate Size(mm) 1300x2000 1500x1500 1500x2500 2000x2000
Plate Daylight (mm) 400 800 400 400
Working Layer 1 1 1 1
Piston Stroke(mm) 400 800 400 400
Unit Press(Mpa) 2.2 3.6 4.0 5.0
Main Motor Power(kw) 8 16.5 11 11
Overall Size(mm) 2000x1860x2500 2200x2200x4300 3000x2500x3300 3600x3000x3300



Heating System Powder Solid Tire Rubber Vulcanizing Press Customization
Heating System Powder Solid Tire Rubber Vulcanizing Press Customization
Heating System Powder Solid Tire Rubber Vulcanizing Press Customization
