Specifications
Brand Name :
SFC
Model Number :
X(S)N-3 X(S)N-20 X(S)N-35 X(S)N-55 X(S)N-75
Certification :
CE、ISO9001、SGS
Place of Origin :
China
MOQ :
1
Price :
US$20000.00-80000.00/set
Payment Terms :
T/T
Supply Ability :
500 sets/year
Delivery Time :
45 days
Packaging Details :
Standard packaging.
Control System :
PLC
Material :
Carbon Steel/Stainless Steel
Operation Mode :
Automatic
Product Name :
Rubber Batch Off Cooler
Voltage :
380V
Warranty :
1 Year
Weight :
Customized
Description
Fully Automatic Temperature Control Rubber Internal Mixer & Rubber Kneader with CE/ISO9001/SGS
Product Features
  • Tipping type mixing tank with dry mechanical shaft seal for easy cleaning and color changes
  • High efficiency with mixing cycles of 6-10 minutes
  • Durable construction with low failure rate, easy installation, operation, and maintenance
  • Built-in timer and alarm systems for process completion and operational alerts
  • Precise material addition and dispensing systems for rubber additives, fillers, and curing agents
  • Safety enclosures for operator protection and noise reduction
  • Accurate automatic temperature and time control system for optimal dispersion and uniform mixing
Product Gallery
Fully Automatic Temperature Control Rubber Internal Mixer with PLC Control System and CE/ISO9001/SGS Certification Fully Automatic Temperature Control Rubber Internal Mixer with PLC Control System and CE/ISO9001/SGS Certification Fully Automatic Temperature Control Rubber Internal Mixer with PLC Control System and CE/ISO9001/SGS Certification Fully Automatic Temperature Control Rubber Internal Mixer with PLC Control System and CE/ISO9001/SGS Certification Fully Automatic Temperature Control Rubber Internal Mixer with PLC Control System and CE/ISO9001/SGS Certification Fully Automatic Temperature Control Rubber Internal Mixer with PLC Control System and CE/ISO9001/SGS Certification Fully Automatic Temperature Control Rubber Internal Mixer with PLC Control System and CE/ISO9001/SGS Certification Fully Automatic Temperature Control Rubber Internal Mixer with PLC Control System and CE/ISO9001/SGS Certification Fully Automatic Temperature Control Rubber Internal Mixer with PLC Control System and CE/ISO9001/SGS Certification
Technical Specifications
Type of Internal Mixer (L) 20L 35L 55L 75L 110L
Mixing Chamber Volume (KW) 20L 35L 55L 75L 110L
Main Motor Power (KW) 37KW 55KW 75KW 110KW 160KW
Tilting Motor Power (KW) 1.5KW 1.5KW 2.2KW 3.75KW 5.5KW
Diameter of Cylinder (mm) Φ200 Φ250 Φ300 Φ350 Φ420
Dust Collector Motor Power (KW) 0.375KW 1.5KW 1.5KW 1.5KW 2.2KW
Tilting Angle (°) 110 110 110 110 110
Feed Mode (F/R) F F F/B F/B F/B
Steam/Cooling Shift Mode Automatic Automatic Automatic Automatic Automatic
Shipping Volume (m³) 12m³ 20m³ 26m³ 29m³ 32m³
Install Dimension (mm) 2350*1550*2400 2570*2180*2570 3370*2460*3180 3550*2560*3220 4245*2950*3380
Chum Up Shaft Forward Speed (RPM) 38/32 38/32 38/32 38/32 38/32
Chum Shaft Backward Speed (RPM) 29/25 29/25 29/25 29/25 29/25
