Auto Spring Loading Machine For Oil Seals,Skeleton Oil Seal,Hydraulic oil Seal, for CFW .LYO .CHR .PHLE. SIMRIT
Auto Spring Loading Machine For Oil Seals,Skeleton Oil Seal,Hydraulic oil Seal, for CFW .LYO .CHR .PHLE. SIMRIT
Specifications
Brand Name :
INTER-CHINA
Model Number :
YH-SM-30,YH-SM-50,
Certification :
ISO9001;CE;SGS;
Place of Origin :
CHINA
Service: :
Accept inspection before shipment and the acceptance criteria of customers' trial sample
Type :
Oil seal machine; Spring Loading machine;
Material availiable :
Rubber,PTFE,NBR,HNBR,ACM,VMQ,VTION SILICONE TEFLONG
Use on :
construction machinery industry, injection molding machine industry, metallurgical industry, the press industry, engineering machinery oil cylinder factory, automobile industry, metallurgy, oil cylinder factory, etc
Description

Auto Spring Loading Machine For Oil Seals,Skeleton Oil Seal,Hydraulic oil Seal, for CFW .LYO .CHR .PHLE. SIMRITAuto Spring Loading Machine For Oil Seals,Skeleton Oil Seal,Hydraulic oil Seal, for CFW .LYO .CHR .PHLE. SIMRITAuto Spring Loading Machine For Oil Seals,Skeleton Oil Seal,Hydraulic oil Seal, for CFW .LYO .CHR .PHLE. SIMRIT


Auto Spring Loading Machine For Oil Seals, Skeleton Oil Seal, Hydraulic oil Seal;

For CFW.LYO.CHR.PHLE. SIMRIT


This machine is suitable for loading the spring with high-volume oil seals in the production line.


Features:

  • The vibrating tray vibrates the rubber parts to the appropriate location.
  • The machine adopts PLC+ industrial touchscreen control, simple operation, and intuitive data, according to the requirements of various non-standard customs.
  • The air cylinder pushes the jig to combine the oil seal with the spring at an extremely fast speed;
  • Automatically detects spring loading via probe
  • For various shapes and sizes.


​
VIDEO OF OUR STRIP CUTTER ON YOUTUBE



Technical Parameters

Structure & Main data

Model

YH-SM-30

YH-SM-50
Oil seal ranges 10~30 30~50
Spring range (mm) ~25 ~45
Air system (Mpa) Requires 0.5~0.8 (80 psi)good clean compressed air;
Electrical Connection Single Phase /AC220V±5%
50/60 Hz
300W
Feeding way of Spring Magnet plate Magnet plate
Feeding way of oil seal Vibrating tray Vibrating tray
　
Function & Performance Operation & Control Mode PLC & HMI
Auto feeding and auto unloading, fully automatic process.
Process:
OIL SEAL: Sorting( Vibrating Tray)→Transmit (Converyor)→Feeding
SPRING: Sorting( Turnover device)→Transmit (Mangenic device)→Feeding

OIL SEAL & SPRING→Fixing →Detection→FILLNG OIL (OPTION)→DISCHARGING
Fixing The air cylinder pushes the jig to combine the oil seal with the spring at an extremely fast speed
Detection Automatically detects spring loading via probe
Efficiency (pcs/min) 15~25 10~20
　
Packing Infos Equipment Weight(KG) 320 380
Equipment Size(cm) 105*80*160 125*90*165




Order Options :

  1. Size of Conveyor;

  2. Color of Machine;

  3. Control Mode: Button or HMI;

  4. OIL FILLING device;
