EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A
EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A
EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A
EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A
EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A
EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A
EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A
EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A
Specifications
Brand Name :
Ke Fei Te
Model Number :
JHS
Certification :
CCC/ISO 9001
Place of Origin :
Chongqing, China
MOQ :
500 meters
Price :
$0.20-1.80/meters
Payment Terms :
L/C,D/A,D/P,T/T,MoneyGram,Western Union
Delivery Time :
5-12days
Packaging Details :
Wooden drum, wooden pallet, plastic pallet, woven bag
Working Temperature :
70°C
Rated Voltage :
450/750V
Rated Current :
16A
Insulation Material :
Rubber
Type :
LOW VOLTAGE
Application :
Submersible Pump Cable
Conductor Material :
Annealed copper conductor
Jacket :
Rubber
Size :
0.75mm²~300mm²
Product Name :
Waterproof Submersible Pump Cable
Shape :
round wire
Feature :
waterproof,cold resistance, soft ,small bending radius,flexible ,movable
Conductor :
Stranded Pure Copper
Insulation :
EPR Rubber Insulation
Voltage :
450/750V
Sheath :
Rubber sheath
Filler :
TPE(thermoplastic elastomer)
Certificate :
ISO9001/CCC
Core :
Single Core,2 3 4 5 6 Cores
Description
450/750V Heavy-Duty and High-Performance Stranded Copper Conductor EPR Insulation Flexible Submersible Water Pump Rubber Cable Wire
450/750V High-Performance Waterproof Ethylene Propylene Rubber Insulation Stranded Copper Conductor Submersible Pump Power Cable available in 2, 3, 4, 5, 6 Core configurations with cross sections ranging from 0.75MM² to 300MM².
JHS submersible cable is a rubber-insulated and sheathed flexible cable specially designed for power supply to submersible pumps in deep wells, rivers, and industrial water systems. With excellent water resistance and mechanical strength, it is ideal for continuous underwater operation.

EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A

Product Overview
This waterproof rubber cable is manufactured using special rubber waterproof material and thermoplastic elastomer filling materials, featuring cold resistance, flexibility, and superior waterproof properties. Designed for connecting submersible motors with DC voltage 450/750V and below, it's ideal for submersible pump power transmission with a long-term allowable operating temperature not exceeding 65°C.
Key Features
  • Conductor: Stranded multiple thin copper wires for maximum flexibility
  • Sheath: High-quality rubber material
  • Insulation: EPR (Ethylene Propylene Rubber)
  • Voltage Rating: 450/750V
  • Filler: TPE (thermoplastic elastomer)
  • Wrapping Tape: Non-woven fabrics
  • Shape: Round design for optimal performance
  • Core Options: Available in Single Core, 2 Cores, 3 Cores, 4 Cores, 5 Cores, 6 Cores
  • Cross Section Range: From 0.75mm to 300mm

EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A

Primary Applications
  • Water Conservancy: Submersible pumps for farmland irrigation, fish pond oxygenation, urban water supply systems, and sewage treatment
  • Construction: Power supply for submersible pumps in sinking well construction and underwater concrete vibrators
  • Municipal Engineering: Temporary power supply for sewer cleaning equipment and river dredging machinery
  • Underwater Operations: Underwater welding, cleaning, and other submerged applications
  • Landscape Lighting: Power transmission for water illumination lamps and water treatment equipment
  • Marine Applications: Bilge pumps on ships, deck equipment, and port shore washers
EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A
Technical Specifications
Product Name Waterproof Rubber Cable
Brand Ke Fei Te
Model JHS
Conductor Material Stranded Copper conductor
Insulation Material EPR
Jacket Rubber
Color Black
Shape Round wire
Features Flame retardant, waterproof, cold resistant, high temperature resistant, highly flexible
Quality Assurance
  • Every production process undergoes specialized quality testing
  • Professional engineers conduct final quality inspections
  • All products meet CCC/ISO9001 certifications and comply with IEC standards
About Chongqing Kefei Cable Group Co., Ltd.
EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A
With 40 years of experience in R&D and production of rubber cables, our company specializes in manufacturing various electrical cables including mining cables, rubber sheath cable series, shield machine special high voltage cables, and other specialized series. Our flexible cable series benefits from over 20 years of expertise and can be customized to meet specific customer requirements.
Our Advantages
  • Advanced production technology
  • High-quality design standards
  • Comprehensive testing equipment
  • Stringent quality control processes
  • Mature and optimized production workflows
Production Facilities
EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A
Certifications
EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A
Packaging & Shipping
EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A EPR Insulation Cold Resistant Submersible Pump Cable JHS Cable 16A
We provide professional, environmentally friendly, and efficient packaging services to ensure the complete safety of your goods during transportation.
Frequently Asked Questions
Q: Are you a manufacturer or a trading company?
A: We are a production manufacturer committed to delivering the highest quality products.
Q: Can you produce and manufacture products according to customer requirements?
A: Yes, we offer customized solutions tailored to your specific requirements.
Q: How can we guarantee quality?
A: We implement pre-production sampling and final inspection protocols before shipment.
Q: How can I place an order?
A: Please provide detailed requirements for an immediate quote. For complex requests, we recommend direct contact via Skype, email, or phone.
