RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS
RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS
RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS
RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS
RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS
RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS
RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS
RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS
RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS
RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS
RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS
RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS
Specifications
Module Rated Capacity :
100Ah
Module Rated Energy :
5.12kWh
System Voltage Range :
100 ~ 750V
Module Rated Voltage :
51.2V
Description

Key Features

RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS

Rack-mounted standard 19-inch design

RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS

LiFePO4 cell for highest safety

RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS

Built-in BMS with multi-protection

RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS

Parallel up to 16 units (81.92kWh)

RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS

6,000+ cycle life with 80% DOD

RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS

Compatible with most inverters

RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS

Compact and space-efficient

RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS

Easy installation and maintenance

Technical Specifications

Rated Voltage51.2V
Rated Capacity100Ah
Rated Energy5.12kWh
Output Voltage Range43.2V ~ 58.4V
Charging Voltage57.6V ~ 58.4V
Cut-off Voltage43.2V
Max Charging Current100A
Recommended Charging Current50A
Max Discharging Current100A
Efficiency>98%
Dimensions (L×W×H)440 × 480 × 155 mm
Weight≈45 kg
Humidity5% ~ 95% RH
Cycle Life>6,000 (0.2C, @25℃, 80% DOD)
Design Life>10 years
Charging Temperature0℃ ~ 55℃
Discharging Temperature-20℃ ~ 60℃
Storage Temperature-5℃ ~ 30℃
Parallel ConnectionUp to 16 units

Application Scenarios

RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS

Villa

RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS

Private Home

RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS

Manor

RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS

Small Farm

RPES HVSM1 20.48 ~ 61.44kWh High Voltage Stackable ESS

Server Room

Certifications

CEIEC62619UN38.3RoHS
