Gold Tin Coating Equipment For Ceramic Tiles , Titanium Nitride Pvd Plating Machine
Gold Tin Coating Equipment For Ceramic Tiles , Titanium Nitride Pvd Plating Machine
Gold Tin Coating Equipment For Ceramic Tiles , Titanium Nitride Pvd Plating Machine
Gold Tin Coating Equipment For Ceramic Tiles , Titanium Nitride Pvd Plating Machine
Gold Tin Coating Equipment For Ceramic Tiles , Titanium Nitride Pvd Plating Machine
Gold Tin Coating Equipment For Ceramic Tiles , Titanium Nitride Pvd Plating Machine
Gold Tin Coating Equipment For Ceramic Tiles , Titanium Nitride Pvd Plating Machine
Gold Tin Coating Equipment For Ceramic Tiles , Titanium Nitride Pvd Plating Machine
Specifications
Brand Name :
ROYAL
Model Number :
RTAC2022
Certification :
CE
Place of Origin :
Made in China
MOQ :
1 set
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
12 sets per month
Delivery Time :
9 to 12 weeks
Packaging Details :
Export standard, to be packed in new cases/cartons, suitable for long-distance ocean/air and inland transportation.
Deposition Sources :
Cathodic Arc evaporation
Deposition Films :
TiN TiO arc plating
Applications :
glass and ceramic mosaics tiles gold coating
Film Features :
wear resistance, strong adhesion, decorative coating colors
Factory Location :
Shanghai city, China
Worldwide Service :
Poland - Europe; Iran- West Asia & Middle East, Turkey, India, Mexico- South America
Training Service :
Machine operation, maintenance, coating process Recipes, program
Warranty :
Limited warranty 1 year for free, whole life for machine
OEM & ODM :
available, we support tailor made design and fabrication
Description

TiN gold coating on Ceramic Tiles, Arc Vacuum PVD Plating Equipment

By using PVD arc evaporation coating technology, deposit many metal materials like: Titanium, Chrome, Copper, Brass, Zirconium to get various colors: gold, silver, black, grey, chroming.
The PVD Arc Vacuum coating equipment consists of: vacuum chamber, vacuum pumps, arc sources, spindle & jack, jigs structure, heating & cooling, water & gas (distribution), electrical control & operation systems, substrate carrier etc.
Ceramic TiN Coating Equipment Advantage: easy to operate, compact foot print, low cost of owner ship, fast substrate exchange.
TiN Coating Film's properties: high shiny and bright colors, strong adhesion & excellent scratch protection.
Gold Tin Coating Equipment For Ceramic Tiles , Titanium Nitride Pvd Plating Machine

The RTAC2022 coating machine has large capacity to guaranty 200 ~300 squre meters coating every 8 hours.
RTAC2022 Specification
MODEL RTAC2022
MATERIAL Stainless Steel (S304)
CHAMBER SIZE Φ2000*2200mm (H)
PUMP SYSTEM Rotary Piston Vacuum Pump (Mechanical)
Rotary Vane Vacuum Pump (Holding)
Roots Vacuum Pump
Diffusion Pump
TECHNOLOGY Ion Plating ( Multi-arc sources)
TYPICAL TARGETS Titanium, Chrome, Zr, Cu, Al etc.
GAS Gas Mass Flow Meters ( Ar, N2,) (Argon, Nitrogen )
CONTROL PLC(Programmable Logic Controller)
SAFETY SYSTEM Numerous safety interlocks to protect operators and equipment
COOLING Water
HEATING Heater
POWER MAX. 150 KW (Approx.)

AVERAGE POWER

CONSUMPTION

 70 KW (Approx.)

Please contact us for more specifications, Royal Technology is honored to provide you total coating solutions.
