Lenovo SR588 2U Rack Server 550W Power 8x2.5 HDD Support
Lenovo SR588 2U Rack Server 550W Power 8x2.5 HDD Support
Lenovo SR588 2U Rack Server 550W Power 8x2.5 HDD Support
Lenovo SR588 2U Rack Server 550W Power 8x2.5 HDD Support
Lenovo SR588 2U Rack Server 550W Power 8x2.5 HDD Support
Lenovo SR588 2U Rack Server 550W Power 8x2.5 HDD Support
Lenovo SR588 2U Rack Server 550W Power 8x2.5 HDD Support
Lenovo SR588 2U Rack Server 550W Power 8x2.5 HDD Support
Specifications
Brand Name :
/
Model Number :
SR588
Place of Origin :
Shanghai, China
MOQ :
2
Price :
$2,300
Rack height :
2U
Processor type :
Intel Xeon Scalable
Max processor cores :
24 per CPU
Max memory :
1TB
Memory speed :
2933MHz
Memory slots :
16
Max hard disks :
16 (2.5-inch) or 12 (3.5-inch)
PCIe slots :
6 PCIe 3.0
Max storage capacity :
168TB (3.5-inch HDD)
Network interfaces :
2 GbE ports
Power supply :
550W/750W Platinum, 750W Titanium
Management :
XClarity Controller
Operating systems :
Microsoft, SUSE, Red Hat, VMware
Security features :
TPM 2.1, TCM optional
Redundancy :
Hot-plug HDD/SSD/NVMe, Hot-swappable power supplies
Description
Product Description

SR588

Len-ovo SR588 Servers Specification

Rack

2U

Processor

Up to 2 second-generation In-tel Xe-on Scalable Processor Platinum Series, up to 150W, up to 24 cores per CPU

Memory

Up to 1TB of 2933MHz TruDDR4 (planned support) memory, using 16 slots, supporting Intel Optane data center persistent memory

Hard Disks

Up to 16 2.5-inch hard drives or 12 3.5-inch hot-swappable hard drives or up to 8 3.5-inch easy-swappable hard drives;

Support up to 4 NVMe hard drives through optional AnyBay backplane

PCIe

Up to 6 PCIe 3.0, various I/O configurations can be flexibly realized through expansion cards

Storage

Up to: 168TB (3.5-inch SAS/SATA HDD);

107.6TB (3.5-inch SSD);

38.4TB (2.5 inch SAS/SATA);

122.9TB (2.5 inch SSD);

16TB (2.5 inches directly connected to NVMe);

Up to 2 M.2 SSDs (support Raid 1)

Network Interfaces

Standard 2 GbE port;

Standard LOM interface;

Optional ML2

Power Supply

Up to 2 hot-plug/redundant 550W/750W Platinum, 750W Titanium

Management

XClarity Administrator;

XClarity Controller (embedded hardware);

Optional XClarity Pro

Operating System

Micro-soft,SUSE,Red Hat,VMware

Security

Len-ovo Think-Shield, lock panel, lock top cover;

Standard TPM 2.1;

Optional TCM

Availability and redundancy

Hot-plug HDD/SSD/NVMe,

Hot-swappable power supplies and fans,

Light path diagnosis,

PFA suitable for all major components, ASHRAE A4 support (limited),

Optional XClarity Pro with remote alarm function.

NIC

Standard 2 GbE ports;

Standard 1 GbE dedicated management port;

Optional up to 2 1GbE, 2 10GBase-T or 2 10GBase SFP+

HBA/RAID

Standard software RAID (up to 8 ports);

Up to 16-port HBA/or hardware RAID with flash cache
