Double Separate Heads Four Axis Cnc Router Metal Carving Machine T - Slot Table
Double Separate Heads Four Axis Cnc Router Metal Carving Machine T - Slot Table
Double Separate Heads Four Axis Cnc Router Metal Carving Machine T - Slot Table
Double Separate Heads Four Axis Cnc Router Metal Carving Machine T - Slot Table
Specifications
Brand Name :
BLUE ELEPHANT
Model Number :
ELE1325
Certification :
CE, ISO9001, SGS, CIQ
Place of Origin :
Jinan City, Shandong Province,China
MOQ :
1set
Price :
15999-20999$
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200sets per Month
Delivery Time :
15-20working days
Packaging Details :
Standard marine export plywood case
Table Surface :
T-slot Table
Frame :
Welded Structure
X, Y Structure :
helical rack, Hiwin Rail Linear Bearings
Z Structure :
Hiwin Rail Linear Bearings and Ball Screw
Spindle Power :
2.2KW water cooling spindle for both heads
Drive Motors :
Stepper System
Description

HIWIN linear guide , imported from Taiwan , China brand hot sale 1325 woodworking cnc router

Application:

Applicable to process various Wooden products,like Solid Wood Furniture and Solid

Wood Door,Decorative Panel,Computer Desk,Office Furniture,Sign Plates,Acrylic

cutting,Vacuum Plastic Moulds,as well as many metal or non-metal materials as copper, aluminum plates, etc.

Features :

1 , 2.2kw water cooling spindle (top brand in China), big strength, long life, and low noise.

2 , Popular DSP controller, it’s with USB interface, no need connecting to PC,both easy operation and convenient.

3 , Double separate heads, much bigger strength than one head, it’s suitable for wood doors, windows, or other wood furniture with symmetrical patterns.

4 , HIWIN linear guide, imported from Taiwan. It’s high precision, long life and top pressure-tolerant performance.

Parameter:

1 X,Y,Z Working Area 1300x2500x200mm
2 X,Y,Z Traveling Positioning Accuracy ±0.03/300mm
3 X,Y,Z Repositioning Accuracy ±0.03mm
4 Table Surface T-slot Table
5 Frame Welded Structure
6 X, Y Structure helical rack, Hiwin Rail Linear Bearings
7 Z Structure Hiwin Rail Linear Bearings and Ball Screw
8 Max. Power Consumption (Without Spindle) 2.5kw~3Kw
9 Max. Rapid Travel Rate 33000mm/min
10 Max. Working Speed 25000mm/min
11 Spindle Power 2.2KW water cooling spindle for both heads
12 Spindle Speed 0-24000RPM
13 Drive Motors Stepper System
14 Working Voltage AC380V V/50/60Hz,3PH (Option: 220V)
15 Command Language G Code
16 Operating System DSP control system(options: NCstudio/Mach3 PC Software)
17 Collet ER20
18 X,Y Resolution <0.01mm
19 Software Compatibility Type3/UcancameV9 Software
20 Running Environment Temperature 0 - 45 Centigrade

Why do customers all over the world prefer our machine much more than other similar products?

1 . Our company has more than 10 years' experience in manufacturing cutting and engraving cnc router machine.

2 . Our machine has achieved CE,FDA,CIQ,which ensures the quality and its longer life time makes customers feel at ease to use it.

3 . Reinforced and thickened machine body makes transportation absolutely safer.

Double Separate Heads Four Axis Cnc Router Metal Carving Machine T - Slot Table

Double Separate Heads Four Axis Cnc Router Metal Carving Machine T - Slot Table
