Precious Metal Through Hole Slip Ring JINPAT 350rpm IP65
Precious Metal Through Hole Slip Ring JINPAT 350rpm IP65
Specifications
Brand Name :
JINPAT
Model Number :
LPT060-1405
Certification :
ISO9001.ISO14000.CE.UL.FCC.RoHS
Place of Origin :
China
MOQ :
1PCS
Price :
Negotiable
Payment Terms :
TT/CC/Paypal
Supply Ability :
1000 units/week
Delivery Time :
2 weeks ARO
Packaging Details :
Standard/On Request
Inner Diameter :
Φ60mm
Working Speed :
0~350rpm
Contact Material :
Precious Metal
Working Temperature :
-20°C~+60°C
IP :
IP68
Rating Voltage :
240VAC/ DC
Lead Wire Length :
Stator:1000mm Rotor:1000mm
Description

Through Bore Slip Ring With 20-50 Amps Circuits

Slip rings enable the transfer of electric power or signal across a rotating part, such as those

found in radar antennae, gun turrets, periscopes, electro-optic sensor gimbals and space satellites. The sliding contact is established by a brush that presses against a metal ring. The “brush” looks like a brush made from metal fibers, but more often it looks like a single wire or a spring with a pad of material affixed to the end that contacts the ring. This LPT060 slip ring with through bore size 60 mm, it can combine with power,signal,Ethernet,USB,Control Net,CANBUS, PROFIBUS, It could also be mounted by shaft or optional flange mounting.

Electronic & Electruc Mechanical
Circuits Total 6CKT Working Speed 0~350rp
Detail 14X5A Inner Diameter Φ60mm
Rating Voltage 240VAC/ DC Contact Material Precious Metal
Dielectric Strength 1000VAC@50Hz Housing Material Aluminum Alloy
Insulation Resistance ≥500MΩ@500VDC Lead Wire Length

Stator:300mm

Rotor:300mm
Environment Remarks
Working Temperature -20°C~+60° Other /
Working Humidity ≤60%RH

LPT060-0605-Outline Drawing

Precious Metal Through Hole Slip Ring JINPAT 350rpm IP65

LPT060-0610-Outline Drawing

Precious Metal Through Hole Slip Ring JINPAT 350rpm IP65

LPT060-0615-Outline Drawing

Precious Metal Through Hole Slip Ring JINPAT 350rpm IP65

LPT060-1205-Outline Drawing

Precious Metal Through Hole Slip Ring JINPAT 350rpm IP65

LPT060-1210-Outline Drawing

Precious Metal Through Hole Slip Ring JINPAT 350rpm IP65

LPT060-1215-Outline Drawing

Precious Metal Through Hole Slip Ring JINPAT 350rpm IP65

LPT060-1405-Outline Drawing

Precious Metal Through Hole Slip Ring JINPAT 350rpm IP65

LPT060-1805-Outline Drawing

Precious Metal Through Hole Slip Ring JINPAT 350rpm IP65

LPT060-1810-Outline Drawing

Precious Metal Through Hole Slip Ring JINPAT 350rpm IP65

LPT060-1815-Outline Drawing

Precious Metal Through Hole Slip Ring JINPAT 350rpm IP65

LPT060-2405-Outline Drawing

Precious Metal Through Hole Slip Ring JINPAT 350rpm IP65

LPT060-2410-Outline Drawing

Precious Metal Through Hole Slip Ring JINPAT 350rpm IP65

LPT060-2410-Outline Drawing

Precious Metal Through Hole Slip Ring JINPAT 350rpm IP65
