Direct Drive YNE226B Model High-Efficiency Screw Air End Compressor Air End
Direct Drive YNE226B Model High-Efficiency Screw Air End Compressor Air End
Specifications
MOQ :
1
Discharge Temperature :
85℃
Packaging Details :
WOODEN CASE
Intake Temperature :
30℃
Supply Ability :
6000 UNIT /MONTH
Atmospheric Humidity :
80%R.H.
Drive :
Direct Drive
Place of Origin :
CHINA
Model Number :
YNE226B
Brand Name :
Bebaios
Intake Pressure :
1 atm
Delivery Time :
1 WEEK
Air End Model :
YNE226B
Payment Terms :
T/T,Western Union
Description
Screw Air End - One Stage
Product Overview
The Heart of Your Compressor: BAOSI High-Efficiency Air Ends. Boost your compressor's performance with BAOSI, the industry's most trusted name for high-performance screw air ends. Known for their exceptional energy-saving capabilities and robust durability, BAOSI air ends help OEMs and maintenance providers reduce operational costs. With a design optimized for lower temperatures and whisper-quiet operation, it is the ultimate "Workhorse" for businesses that demand 24/7 reliability without the premium price tag.
Application Scenarios
  • Laser Cutting Industry: Providing the high-pressure (16-20 bar) stable air flow required for clean, precise cutting edges.
  • General Manufacturing: Powering assembly lines, pneumatic tools, and automation in electronics and automotive plants.
  • Mining & Construction: Integrated into portable units for rock drilling and sandblasting in harsh, dusty conditions.
Technical Specifications
Speed (rpm) performance parameters across different operating conditions:
Speed (rpm) Parameter 0.7 0.8 1.0 1.25 1.5 1.7
1480 Shaft Power (kW) 88.10 92.10 101.50 118.80 140.10 159.90
Air Capacity (m³/min) 14.31 14.26 14.16 14.00 13.77 13.55
Oil Consumption (kW) 70.50 73.70 81.20 95.00 112.10 127.90
Oil Injection (L/min) 116.30 122.70 137.90 165.80 200.10 232.00
1780 Shaft Power (kW) 105.70 110.50 121.80 142.60 168.10 191.90
Air Capacity (m³/min) 17.34 17.28 17.16 16.96 16.69 16.42
Oil Consumption (kW) 84.60 88.40 97.40 114.00 134.50 153.50
Oil Injection (L/min) 139.30 146.90 165.10 198.60 239.80 278.10
2200 Shaft Power (kW) 131.70 137.60 151.70 177.60 209.40 239.00
Air Capacity (m³/min) 21.61 21.54 21.39 21.14 20.81 20.46
Oil Consumption (kW) 105.40 110.10 121.40 142.10 167.50 191.20
Oil Injection (L/min) 173.50 183.10 205.70 247.40 298.70 346.50
2975 Shaft Power (kW) 178.00 186.00 205.00 240.00 283.00 323.00
Air Capacity (m³/min) 29.50 29.40 29.20 28.86 28.40 27.93
Oil Consumption (kW) 142.40 148.80 164.00 192.00 226.40 258.40
Oil Injection (L/min) 233.90 246.90 277.50 333.90 403.20 467.80
3570 Shaft Power (kW) 220.00 229.90 253.40 296.60 349.80 399.20
Air Capacity (m³/min) 35.22 35.10 34.86 34.46 33.91 33.35
Oil Consumption (kW) 176.00 183.90 202.70 237.30 279.80 319.40
Oil Injection (L/min) 291.20 307.20 345.10 414.70 500.40 580.10
Direct Drive YNE226B Model High-Efficiency Screw Air End Compressor Air End
Company Information
Shenzhen Bebaios Machinery Co., Ltd. has been specializing in the production and export of air compressors for over 10 years. We have a 5,000-square-meter factory in Huizhou, Guangdong, with an annual output of 50,000 units.
The company has achieved breakthroughs in after-sales service, design, installation, maintenance, and technical consulting, and has established long-term and close cooperative relationships with many countries around the world. Adhering to the principles of "focus, reliability, innovation, and professionalism," we will continue to provide the highest quality products to both new and existing customers.
Frequently Asked Questions
What is the production capacity of your factory?
Approximately 6,000 units per month.
What about the lead time?
30 days.
Which port do you ship from?
Shenzhen
Can I use a BAOSI air end to replace a GHH or Aerzen unit?
Yes, BAOSI air ends are often used as high-quality replacements. However, we recommend checking the installation dimensions and port locations. Our technical team can provide cross-reference drawings for your convenience.
What makes BAOSI rotors different from other brands?
BAOSI uses German-imported KAPP grinding machines to ensure rotor accuracy. Our patented 5:6 profile is specifically optimized for high volumetric efficiency and lower thermal expansion.
